Page 365 - ASEAN Chainflex Catalogue 2023

CF885.PE PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF885.PE
PVC Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PVC
15 x d ® Oil resistance none 1 2 3 4 highest 15 x d
Spindle cable/Single core | PVC | chainflex CF885.PE Class 3.1.1.1 Torsion none 1 2 3 4 ±360°

5,000,000 15 x d 10m EAC Certificate No. RU C-DE.ME77.B.00302/19
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®
REACH In accordance with regulation (EC) No. 1907/2006 (REACH)

z For flexing applications Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
z PVC outer jacket
z Flame-retardant CE Following 2014/35/EU

UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)

Dynamic information
®
Bend radius e-chain linear minimum 15 x d Guaranteed service life (details see page 28-29)
flexible minimum 12 x d Double strokes* 1 million 3 million 5 million

fixed minimum 8 x d Temperature, R min. R min. R min.
Temperature e-chain linear +5°C up to +70°C from/to [°C] [factor x d] [factor x d] [factor x d]
®
flexible -5°C up to +70°C (following DIN EN 60811-504) +5/+15 17.5 18.5 19.5
fixed -15°C up to +70°C (following DIN EN 50305) +15/+60 15 16 17
v max. unsupported 3m/s +60/+70 17.5 18.5 19.5
* Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
a max. 20m/s²
Typical application areas
Travel distance Unsupported travels up to 10m, Class 1 z For flexing applications, Class 3
z Especially for unsupported travels, Class 1
Cable structure z Without influence of oil, Class 1
Conductor Conductor consisting of bare copper wires (according to DIN EN 60228). z No torsion, Class 1
z Preferably indoor applications
Core insulation Mechanically high-quality PVC mixture. z Wood/stone processing, packaging industry, feeding, handling, adjusting devices

Core identification Green-yellow Part No. Number of cores and conductor Outer diameter Copper Weight

nominal cross section (d) max. index
Outer jacket Low-adhesion PVC mixture, adapted to suit the requirements in e-chains . [mm²] [mm] [kg/km] [kg/km]
®
Colour: Pastel orange (similar to RAL 2003) CF885.PE.25.01 1G2.5 6.5 25 59
CF885.PE.40.01 1G4.0 7.5 61 83
Electrical information CF885.PE.60.01 1G6.0 8.0 61 100
Nominal voltage 600/1,000V (following DIN VDE 0298-3) CF885.PE.100.01 1G10 9.5 100 155
600V (following UL) CF885.PE.160.01 1G16 11.0 159 226
Testing voltage 4,000V (following DIN EN 50395) CF885.PE.250.01 1G25 12.5 248 342
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core
Properties and approvals
Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame
®
Cables available in the chainflex CASE
Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status Simple savings on delivery, storage space and re-ordering with
1992) the chainflex CASE - ship'n store by igus .
®
®
UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and More on this on page 24/25 and online: www.igus-asean.com/cf-case
service life calculator based on 2 billion test cycles per year"
UL/CSA AWM See data sheet for details  www.igus-asean.com/CF885PE

Example image NFPA Following NFPA 79-2018, chapter 12.9

EPLAN download, configurators  www.igus-asean.com/CF885PE
