CF270.UL.D PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF270.UL.D
PUR Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PUR
10 x d ® Oil resistance none 1 2 3 4 highest 10 x d
Spindle cable/Single core | PUR | chainflex CF270.UL.D Class 4.2.3.1 Torsion none 1 2 3 4 ±360°

10 million 10 x d 10m UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
service life calculator based on 2 billion test cycles per year"
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®
UL/CSA AWM See data sheet for details  www.igus-asean.com/CF270ULD

z For medium duty applications z Notch-resistant NFPA Following NFPA 79-2018, chapter 12.9
z PUR outer jacket z Flame-retardant
z Shielded z Hydrolysis and microbe-resistant EAC Certificate No. RU C-DE.ME77.B.00863/20
z Oil-resistant and coolant-resistant z PVC and halogen-free
REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
Dynamic information
®
Bend radius e-chain linear minimum 10 x d Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
flexible minimum 8 x d
fixed minimum 5 x d Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
®
Temperature e-chain linear -25°C up to +80°C CF77.UL.05.12.D - tested by IPA according to standard DIN EN ISO 14644-1
flexible -40°C up to +80°C (following DIN EN 60811-504) DESINA According to VDW, DESINA standardisation
fixed -50°C up to +80°C (following DIN EN 50305)
v max. unsupported 10m/s CE Following 2014/35/EU
gliding 2m/s
a max. 50m/s² UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)

Travel distance Unsupported travels and up to 10m for gliding applications, Class 2
Guaranteed service life (details see page 28-29)
Cable structure Double strokes* 5 million 7.5 million 10 million

Conductor Conductor cable consisting of pre-leads (following DIN EN 60228). Temperature, R min. R min. R min.
from/to [°C] [factor x d] [factor x d] [factor x d]
Core insulation Mechanically high-quality TPE mixture. -25/-15 12.5 13.5 14.5
-15/+70 10 11 12
Overall shield Bending-resistant braiding made of tinned copper wires. +70/+80 12.5 13.5 14.5
Coverage linear approx. 55%, optical approx. 80% * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Outer jacket Low-adhesion, halogen-free, highly abrasion resistant PUR mixture, adapted to
®
suit the requirements in e-chains (following DIN EN 50363-10-2) Typical application areas
Colour: Pastel orange (similar to RAL 2003) z For medium duty applications, Class 4
Electrical information z Unsupported travels and up to 10m for gliding applications, Class 2
Nominal voltage 600/1,000V (following DIN VDE 0298-3) z Almost unlimited resistance to oil, Class 3
1,000V (following UL) z No torsion, Class 1
Testing voltage 4,000V (following DIN EN 50395) z Indoor and outdoor applications without direct sun radiation
z Machining units/machine tools, low temperature applications
Properties and approvals
UV resistance Medium
Number of cores and conductor Outer diameter Copper
Part No. Weight
Oil resistance Oil-resistant (following DIN EN 50363-10-2), Class 3 nominal cross section (d) max. index
[mm²] [mm] [kg/km] [kg/km]
Offshore MUD-resistant following NEK 606 - status 2016 CF270.UL.60.01.D (1x6.0)C 7.5 72 95
CF270.UL.100.01.D (1x10)C 8.5 114 145
Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame CF270.UL.160.01.D (1x16)C 9.5 178 209
CF270.UL.250.01.D (1x25)C 11.0 269 304
Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status CF270.UL.350.01.D (1x35)C 13.0 374 419
(1x50)C
579
15.0
525
CF270.UL.500.01.D
1992)
Example image Halogen-free Following DIN EN 60754 Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. 751 804
17.0
(1x70)C
CF270.UL.700.01.D
G = with green-yellow earth core x = without earth core
EPLAN download, configurators  www.igus-asean.com/CF270ULD
