CF300.UL.D PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF300.UL.D
TPE Travel distance unsupported 1 2 3 4 5 6 ≥ 400m TPE
7.5 x d ® Oil resistance none 1 2 3 4 highest 7.5 x d
Spindle cable/Single core | TPE | chainflex CF300.UL.D Class 6.6.4.2 Torsion none 1 2 3 4 ±360°

10 million 7.5 x d 400m NFPA Following NFPA 79-2018, chapter 12.9
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®
DNV Type Approval Certificate TAE00003XC

z For extremely heavy duty applications z UV-resistant EAC Certificate No. RU C-DE.ME77.B.00863/20
z TPE outer jacket z Hydrolysis and microbe-resistant
z Oil and bio-oil-resistant REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
z Flame-retardant
Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
Dynamic information
®
Bend radius e-chain linear minimum 7.5 x d Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
flexible minimum 6 x d CF34.UL.25.04.D - tested by IPA according to standard DIN EN ISO 14644-1
fixed minimum 4 x d DESINA According to VDW, DESINA standardisation
Temperature e-chain linear -35°C up to +90°C
®
flexible -45°C up to +90°C (following DIN EN 60811-504) CE Following 2014/35/EU
fixed -50°C up to +90°C (following DIN EN 50305)
v max. unsupported 10m/s UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
gliding 6m/s
a max. 100m/s²
Guaranteed service life (details see page 28-29)
Travel distance Unsupported travels and up to 400m and more for gliding applications, Class 6 Double strokes* 5 million 7.5 million 10 million

Temperature, R min. R min. R min.
Torsion Torsion ±90°, with 1m cable length, Class 2 from/to [°C] [factor x d] [factor x d] [factor x d]
-35/-25 10 11 12
Cable structure -25/+80 7.5 8.5 9.5
Conductor Conductor cable consisting of pre-leads (following DIN EN 60228). +80/+90 10 11 12
* Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Core insulation Mechanically high-quality TPE mixture.
Typical application areas
Outer jacket Low-adhesion, extremely abrasion-resistant and highly flexible TPE mixture, z For heavy-duty applications, Class 6
adapted to suit the requirements in e-chains . z Unsupported travels and up to 400m and more for gliding applications, Class 6
®
Colour: Signal black (similar to RAL 9004) z Almost unlimited resistance to oil, also with bio-oils, Class 4
Electrical information z Torsion ±90°, with 1m cable length, Class 2
Nominal voltage 600/1,000V (following DIN VDE 0298-3) z Indoor and outdoor applications, UV-resistant
1,000V (following UL) z Storage and retrieval units for high-bay warehouses, machining units/machine tools, quick
Testing voltage 4,000V (following DIN EN 50395) handling, cleanroom, semiconductor insertion, outdoor cranes, low-temperature applications

Properties and approvals Part No. Number of cores and conductor Outer diameter Copper Weight
UV resistance High nominal cross section (d) max. index
[mm²] [mm] [kg/km] [kg/km]
Oil resistance Oil-resistant (following DIN EN 60811-404), bio-oil-resistant (following VDMA CF300.UL.40.01.D 1x4.0 6.0 41 59
24568 with Plantocut 8 S-MB tested by DEA), Class 4 CF300.UL.60.01.D 1x6.0 7.0 61 83
Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame CF300.UL.100.01.D 1x10 7.5 100 124
CF300.UL.160.01.D 1x16 9.5 159 195
Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status CF300.UL.250.01.D 1x25 11.5 248 294
1992) CF300.UL.350.01.D 1x35 12.5 347 395
UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and CF300.UL.500.01.D 1x50 14.5 495 551
710
1x70
CF300.UL.700.01.D
769
16.5
service life calculator based on 2 billion test cycles per year"
Example image UL/CSA AWM See data sheet for details  www.igus-asean.com/CF300ULD CF300.UL.950.01.D 1x120 20.0 1184 1042
936
1x95
CF300.UL.1200.01.D
1295
21.5
EPLAN download, configurators  www.igus-asean.com/CF300ULD CF300.UL.1500.01.D 1x150 23.5 1469 1579
2052
1928
CF300.UL.1850.01.D
1x185
26.5
