CF310.UL PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF310.UL
TPE Travel distance unsupported 1 2 3 4 5 6 ≥ 400m TPE
7.5 x d ® Oil resistance none 1 2 3 4 highest 7.5 x d
Spindle cable/Single core | TPE | chainflex CF310.UL Class 6.6.4.1 Torsion none 1 2 3 4 ±360°

10 million 7.5 x d 400m NFPA Following NFPA 79-2018, chapter 12.9
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®
DNV Type Approval Certificate TAE00003XC

z For extremely heavy duty applications z Flame-retardant EAC Certificate No. RU C-DE.ME77.B.00863/20
z TPE outer jacket z UV-resistant
z Shielded z Hydrolysis and microbe-resistant REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
z Oil and bio-oil-resistant
Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
Dynamic information
Bend radius e-chain linear minimum 7.5 x d Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
®
flexible minimum 6 x d CF34.UL.25.04.D - tested by IPA according to standard DIN EN ISO 14644-1
fixed minimum 4 x d CE Following 2014/35/EU
Temperature e-chain linear -35°C up to +90°C
®
flexible -45°C up to +90°C (following DIN EN 60811-504) UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
fixed -50°C up to +90°C (following DIN EN 50305)
v max. unsupported 10m/s
gliding 6m/s Guaranteed service life (details see page 28-29)
a max. 100m/s² Double strokes* 5 million 7.5 million 10 million

Temperature, R min. R min. R min.
Travel distance Unsupported travels and up to 400m and more for gliding applications, Class 6 from/to [°C] [factor x d] [factor x d] [factor x d]
-35/-25 10 11 12
Cable structure -25/+80 7.5 8.5 9.5
Conductor Conductor cable consisting of pre-leads (following DIN EN 60228). +80/+90 10 11 12
* Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Core insulation Mechanically high-quality TPE mixture.
Typical application areas
Overall shield Extremely bending-resistant braiding made of tinned copper wires. z For heavy-duty applications, Class 6
Coverage linear approx. 70%, optical approx. 90% z Unsupported travels and up to 400m and more for gliding applications, Class 6
Outer jacket Low-adhesion, extremely abrasion-resistant and highly flexible TPE mixture, z Almost unlimited resistance to oil, also with bio-oils, Class 4
®
adapted to suit the requirements in e-chains . z No torsion, Class 1
Colour: Signal black (similar to RAL 9004) z Indoor and outdoor applications, UV-resistant
Electrical information z Storage and retrieval units for high-bay warehouses, machining units/machine tools, quick
Nominal voltage 600/1,000V (following DIN VDE 0298-3) handling, cleanroom, semiconductor insertion, outdoor cranes, low-temperature applications
1,000V (following UL)
Testing voltage 4,000V (following DIN EN 50395) Part No. Number of cores and conductor Outer diameter Copper Weight
nominal cross section (d) max. index

[mm²] [mm] [kg/km] [kg/km]
Properties and approvals
UV resistance High CF310.UL.25.01 (1x2.5)C 6.0 41 58
CF310.UL.40.01 (1x4.0)C 6.5 57 77
CF310.UL.60.01 (1x6.0)C 7.0 80 101
Oil resistance Oil-resistant (following DIN EN 60811-404), bio-oil-resistant (following VDMA
24568 with Plantocut 8 S-MB tested by DEA), Class 4 CF310.UL.100.01 (1x10)C 8.5 121 146
Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame CF310.UL.160.01 (1x16)C 10.0 184 223
CF310.UL.250.01 (1x25)C 12.0 280 329
CF310.UL.350.01 (1x35)C 13.0 395 444
Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
1992) CF310.UL.500.01 (1x50)C 15.0 536 587
851
779
UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and CF310.UL.700.01 (1x70)C 18.0 1015 1125
(1x95)C
21.0
CF310.UL.950.01
service life calculator based on 2 billion test cycles per year"
Example image UL/CSA AWM See data sheet for details  www.igus-asean.com/CF310UL CF310.UL.1200.01 (1x120)C 22.0 1270 1378
24.5
CF310.UL.1500.01
1592
1700
(1x150)C
CF310.UL.1850.01
(1x185)C
27.5
EPLAN download, configurators  www.igus-asean.com/CF310UL Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. 2066 2189
