CFROBOT5 PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CFROBOT5
TPE Travel distance unsupported 1 2 3 4 5 6 ≥ 400m TPE
±180°/m ® Oil resistance none 1 2 3 4 highest ±180°/m
Fibre Optic Cable | TPE | chainflex CFROBOT5 Class 6.1.4.3 Torsion none 1 2 3 4 ±360°

10 million 10 x d ±180°/m Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
CF9.15.07 - tested by IPA according to standard DIN EN ISO 14644-1
Cycles guaranteed Bend radius, e-chain ® Torsion angle
CE Following 2014/35/EU

z For torsion applications z Low-temperature-flexible UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
z TPE outer jacket z Hydrolysis and microbe-resistant
z Oil and bio-oil-resistant z PVC and halogen-free
z UV-resistant Guaranteed service life (details see page 28-29)
Cycles* 5 million 7.5 million 10 million
Temperature, Torsion max. Torsion max. Torsion max.
Dynamic information from/to [°C] [°/m] [°/m] [°/m]
Bend radius flexible twisted minimum 10 x d -35/-25 ±150 ±90 ±30
fixed minimum 5 x d -25/+70 ±180 ±120 ±60
Temperature flexible twisted -25°C up to +80°C +70/+80 ±150 ±90 ±30
fixed -55°C up to +80°C (following DIN EN 50305) * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
v max. twisted 180°/s
Typical application areas
a max. twisted 60°/s² z For heaviest duty applications with torsion movements, Class 6
z Especially for robots and 3D movements, Class 1
Travel distance Robots and 3D movements, Class 1 z Almost unlimited resistance to oil, also with bio-oils, Class 4
z Torsion ±180°, with 1m cable length, Class 3
Torsion Torsion ±180°, with 1m cable length, Class 3 z Indoor and outdoor applications, UV-resistant
z Robots, handling
Cable structure
Conductor 50/125μm, 62.5/125μm bending-resistant solid glass fibre optic cores, with Number of fibres/ Outer diameter
aramid strain relief elements. Part No. Fibre diameter/ (d) max. Weight
Core structure FOC cores wound with high-tensile aramid dampers around a glass-fibre Conductor nominal cross section
reinforced plastic central element. [mm] [kg/km]
Core identification  Product range table CFROBOT5.500 11) 2x62.5/125 8.5 53
CFROBOT5.501 2x50/125 8.5 53

Outer jacket Low-adhesion, extremely abrasion-resistant and highly flexible TPE mixture, 11) Phase-out model
®
adapted to suit the requirements in e-chains . Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
Colour: jet black (similar to RAL 9005) G = with green-yellow earth core x = without earth core
Properties and approvals
UV resistance High Bandwidth Attenuation Bandwidth Attenuation
Part No. [MHz x km] [dB/km] [MHz x km] [dB/km] Fibre identification
Oil resistance Oil-resistant (following DIN EN 60811-404), bio-oil-resistant (following VDMA @ 650nm @ 650nm @ 850nm @ 850nm
24568 with Plantocut 8 S-MB tested by DEA), Class 4 CFROBOT5.500 11) ≥ 200 ≤ 3.0 ≥ 500 ≤ 0.7 orange with white numbers
Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status CFROBOT5.501 ≥ 500 ≤ 2.5 ≥ 500 ≤ 0.7 blue with white numbers
1992)
Halogen-free Following DIN EN 60754 Cables available in the chainflex CASE
®
Simple savings on delivery, storage space and re-ordering with
UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and the chainflex CASE - ship'n store by igus .
®
®
service life calculator based on 2 billion test cycles per year" More on this on page 24/25 and online: www.igus-asean.com/cf-case
REACH In accordance with regulation (EC) No. 1907/2006 (REACH)

Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
Example image

EPLAN download, configurators  www.igus-asean.com/CFROBOT5
