CFFLAT PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CFFLAT
TPE Travel distance unsupported 1 2 3 4 5 6 ≥ 400m TPE
5 x d ® Oil resistance none 1 2 3 4 highest 5 x d
Single core flat cable | TPE | chainflex CFFLAT Class 7.5.4.1 Torsion none 1 2 3 4 ±360°

Properties and approvals
z For heaviest duty applications UV resistance High
z TPE outer jacket
z Oil and bio-oil-resistant Oil resistance Oil-resistant (following DIN EN 60811-404), bio-oil-resistant (following VDMA
z PVC and halogen-free 24568 with Plantocut 8 S-MB tested by DEA), Class 4
z UV-resistant Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
z Hydrolysis and microbe-resistant 1992)
Halogen-free Following DIN EN 60754

UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
Dynamic information service life calculator based on 2 billion test cycles per year"
®
Bend radius e-chain linear minimum 5 x d EAC Certificate No. RU C-DE.ME77.B.00863/20
flexible minimum 4 x d
fixed minimum 3 x d REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
Temperature e-chain linear -35°C up to +90°C
®
flexible -50°C up to +90°C (following DIN EN 60811-504) Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
fixed -55°C up to +90°C (following DIN EN 50305)
v max. unsupported 10m/s Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
gliding 6m/s CF9.15.07 - tested by IPA according to standard DIN EN ISO 14644-1
a max. 100m/s² CE Following 2014/35/EU

Travel distance Unsupported travels and up to 100m for gliding applications, Class 5 UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)

Cable structure
Conductor Highly flexible braided special conductor. Typical application areas
z For heavy-duty applications, Class 7
Core insulation Mechanically high-quality TPE mixture. z Unsupported travels and up to 100m for gliding applications, Class 5
z Almost unlimited resistance to oil, also with bio-oils, Class 4
Outer jacket Low-adhesion, extremely abrasion-resistant and highly flexible TPE mixture, z No torsion, Class 1
®
adapted to suit the requirements in e-chains . z Indoor and outdoor applications, UV-resistant
Colour: Steel blue (similar to RAL 5011) z Storage and retrieval units for high-bay warehouses, for small installation spaces and bend radii,
Electrical information machining units/machine tools, quick handling, cleanroom, semiconductor insertion,
Nominal voltage 600/1,000V (following DIN VDE 0298-3) low-temperature applications

Testing voltage 4,000V (following DIN EN 50395) Part No. Number of cores and conductor Outer Copper Weight

nominal cross section dimensions index
[mm²] [mm] [kg/km] [kg/km]
CFFLAT.40.01 1x4.0 14.0x5.5 48 117

Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core

Example image
