CFCLEAN3 New CFCLEAN3
Data elements | chainflex CFCLEAN3
®

20 million Min. 70mm 3m Properties and approvals Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
Silicone-free
®
Double strokes guaranteed bend radius e-skin flat travel distance e-skin flat
®
1992)
UL verified Certificate No. B129699: „igus 36-month chainflex cable guarantee and service
®
z For heaviest duty applications in e-skin flat Now with life calculator based on 2 billion test cycles per year“
z PTFE foil wrap UL AWM See data sheet for details u www.igus-asean.com/CFCLEAN3
z Shielded UL approval
z Highly abrasion-resistant in combination REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
z PVC-free with e-skin flat
®
Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)

Cleanroom Air Purity Class 1, material/stranded structure tested by IPA according to
ISO 14644-14, test report IG 2107-1242
Dynamic information CE Following 2014/35/EU
®
Bend radius e-skin flat linear minimum 70mm
(further radii in preparation, please see data sheet) UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
fixed minimum 3 x d
®
Temperature e-skin linear -10°C up to +80°C
fixed -25°C up to +90°C (following DIN EN 50305) Typical application areas
v max. unsupported 2m/s z For heaviest duty applications and especially small radii in cleanroom with e-skin flat
®
z Especially for short, very fast applications with small radii and restricted installation space
a max. 40m/s² z Indoor applications with e-skin flat
®
z Semi-conductor/OLED manufacturing, medical cleanroom
Travel distance Short, very fast applications with small radii and restricted installation space in
®
an e-skin flat chainflex CFCLEAN are not cables in the sense of the normal standards for cables. Due
®
Cable structure to the absence of the outer jacket in CFCLEAN, which provides mechanical protection for
Conductor Very finely stranded special conductors with especially soft and bending cables, the use of chainflex CFCLEAN is only permitted inside e-skin flat.
®
®
resistant design, made of bare copper wires.
Core insulation Mechanically high-quality FEP mixture.

Core structure Cores twisted in pairs with a short pitch length, core pairs then wound with Part No. Number of cores and conductor Outer diameter Copper Weight
short pitch lengths. nominal cross section (d) max. index
Core identification u Product range table [mm²] [mm] [kg/km] [kg/km]
CFCLEAN3.01.05.02 (5x(2x0.14))C 5.0 33 43

Overall shield Extremely bending-resistant braiding made of tinned copper wires. CFCLEAN3.01.06.02 (6x(2x0.14))C 5.5 36 50
Coverage linear approx. 70%, optical approx. 90% CFCLEAN3.01.08.02 (8x(2x0.14))C 6.0 47 61
Outer film Low-adhesion, extremely abrasion-resistant and highly flexible PTFE wrap, CFCLEAN3.02.03.02 (3x(2x0.25))C 5.0 34 44
®
adapted to suit the requirements in e-skin flat. CFCLEAN3.02.04.02 (4x(2x0.25))C 5.5 42 58
Colour: White CFCLEAN3.02.05.02 (5x(2x0.25))C 5.5 50 63
Electrical information CFCLEAN3.02.06.02 (6x(2x0.25))C 6.0 52 70
Nominal voltage 300/300V Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core
300V (following UL)
Testing voltage 2,000V
Part No. Core identification
CFCLEAN3.01.05.02 brown/white, green/white, yellow/white, grey/white, pink/white
CFCLEAN3.01.06.02 brown/white, green/white, yellow/white, grey/white, pink/white, blue/white
brown/white, green/white, yellow/white, grey/white, pink/white, blue/white, red/
CFCLEAN3.01.08.02 white
black/white
Example image CFCLEAN3.02.03.02 brown/white, green/white, yellow/white
CFCLEAN3.02.04.02
brown/white, green/white, yellow/white, grey/white
CFCLEAN3.02.05.02
brown/white, green/white, yellow/white, grey/white, pink/white
ASEAN2023 ASEAN2023 CFCLEAN3.02.06.02 brown/white, green/white, yellow/white, grey/white, pink/white, blue/white
