CFCLEAN8 CFCLEAN8
Bus elements | chainflex CFCLEAN8
®

20 million Min. 70mm 3m Properties and approvals Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
Silicone-free
®
Double strokes guaranteed bend radius e-skin flat travel distance e-skin flat
®
1992)
UL verified Certificate No. B129699: „igus 36-month chainflex cable guarantee and service
®
z For heaviest duty applications in e-skin flat life calculator based on 2 billion test cycles per year“
z PTFE foil wrap UL AWM See data sheet for details u www.igus-asean.com/CFCLEAN8
z Shielded
z Highly abrasion-resistant REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
z PVC-free
Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)

Cleanroom Air Purity Class 1, material/stranded structure tested by IPA according to
ISO 14644-14, test report IG 2107-1242
Dynamic information CE Following 2014/35/EU
®
Bend radius e-skin flat linear minimum 70mm
(further radii in preparation, please see data sheet) UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
fixed minimum 3 x d
®
Temperature e-skin linear -10°C up to +80°C
fixed -25°C up to +90°C (following DIN EN 50305) Typical application areas
v max. unsupported 2m/s z For heaviest duty applications and especially small radii in cleanroom with e-skin flat
®
z Especially for short, very fast applications with small radii and restricted installation space
®
a max. 40m/s² z Indoor applications with e-skin flat
z Semi-conductor/OLED manufacturing, medical cleanroom
Travel distance Short, very fast applications with small radii and restricted installation space in
®
®
an e-skin flat chainflex CFCLEAN are not cables in the sense of the normal standards for cables. Due
Cable structure to the absence of the outer jacket in CFCLEAN, which provides mechanical protection for
®
®
Conductor Very finely stranded special conductors with especially soft and bending cables, the use of chainflex CFCLEAN is only permitted inside e-skin flat.
resistant design, made of bare copper wires.
Core insulation Mechanically high-quality FEP mixture.

Core structure According to bus specification. Number of cores and conductor Outer diameter Copper
Part No. Weight
nominal cross section (d) max. index
Core identification According to bus specification. [mm²] [mm] [kg/km] [kg/km]
u Product range table Ethernet/CAT5e
Overall shield Extremely bending-resistant braiding made of tinned copper wires. CFCLEAN8.045 (4x(2x0.14))C 5.5 34 47
Coverage linear approx. 70%, optical approx. 90% Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core
Outer film Low-adhesion, extremely abrasion-resistant and highly flexible PTFE wrap,
adapted to suit the requirements in e-skin flat.
®
Colour: White
Electrical information Characteristic wave
Nominal voltage 300/300V Part No. impedance approx. Core group Colour code
[Ω]
Testing voltage 2,000V Ethernet/CAT5e
CFCLEAN8.045 100 4x(2x0.14) white/blue, white/orange,
white/green, white/brown

Example image

ASEAN2023 ASEAN2023

36-month guarantee ... more than 1,350 cable types from stock ... no cutting charges UL-verified chainflex guarantee ... www.igus-asean.com/ul-verified 461
®
