Network Network
Profinet Industrial Profinet cables Industrial Profinet cables Profinet
with moulded connectors moulded

* Technical information on the cable quality: * Technical information on the cable quality:
PVC, oil-res. PUR PVC, oil-res. PUR
Page 192 Page 200 Page 192 Page 200

Price class from 7 cables
Price class 4-6 cables
Industrial Profinet moulded, to your required length Price class 1-3 cables Industrial Profinet moulded, to your required length
Number of cores and conductor Number of cores and conductor
Cable quality Part No. Ø Bend radius Cable quality Part No. Ø Bend radius
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
M8 cable socket/ M12 cable connector d-coded/
M8 cable connector RJ45 straight

PVC, oil-res. MAT904125470 (4x0.38)C 7.0 12.5 PVC, oil-res. MAT904125477 (4x0.38)C 7.0 12.5
PUR MAT904125430 (4x0.38)C 7.0 12.5
PUR MAT904125437 (4x0.38)C 7.0 12.5
M8 cable connector/
M8 cable connector
M12 angled connector d-coded
PVC, oil-res. MAT904125471 (4x0.38)C 7.0 12.5 RJ45 straight
PUR MAT904125431 (4x0.38)C 7.0 12.5

PVC, oil-res. MAT904125478 (4x0.38)C 7.0 12.5
M8 angled socket/
open cable end PUR MAT904125438 (4x0.38)C 7.0 12.5
M12 cable connector d-coded/
PVC, oil-res. MAT904125472 (4x0.38)C 7.0 12.5 M8 cable connector
PUR MAT904125432 (4x0.38)C 7.0 12.5 PVC, oil-res. MAT904125479 (4x0.38)C 7.0 12.5

M8 cable socket/ PUR MAT904125439 (4x0.38)C 7.0 12.5
RJ45 straight
RJ45 straight/
PVC, oil-res. MAT904125473 (4x0.38)C 7.0 12.5 RJ45 straight
PUR MAT904125433 (4x0.38)C 7.0 12.5 PVC, oil-res. MAT904125480 (4x0.38)C 7.0 12.5
PUR MAT904125440 (4x0.38)C 7.0 12.5
M12 cable connector d-coded/
M12 cable connector d-coded RJ45 straight/
open cable end
PVC, oil-res. MAT904125474 (4x0.38)C 7.0 12.5
PUR MAT904125434 (4x0.38)C 7.0 12.5 PVC, oil-res. MAT904125481 (4x0.38)C 7.0 12.5
PUR MAT904125441 (4x0.38)C 7.0 12.5

M12 angled connector d-coded/ M12 cable socket d-coded/
open cable end M12 cable connector d-coded
PVC, oil-res. MAT904125482 (4x0.38)C 7.0 12.5
PUR MAT904125442 (4x0.38)C 7.0 12.5
PVC, oil-res. MAT904125475 (4x0.38)C 7.0 12.5
PUR MAT904125435 (4x0.38)C 7.0 12.5
M12 cable socket d-coded/
M12 cable connector d-coded/ M12 cable connector d-coded
open cable end
PVC, oil-res. MAT904125476 (4x0.38)C 7.0 12.5 PVC, oil-res. MAT904125483 (4x0.38)C 7.0 12.5
PUR MAT904125436 (4x0.38)C 7.0 12.5
PUR MAT904125443 (4x0.38)C 7.0 12.5

Special production cables  delivery time upon request Special production cables  delivery time upon request
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core G = with green-yellow earth core x = without earth core
Harnessing RJ45 at both endsTIA56A Harnessing RJ45 at both endsTIA56A
®
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
