Harnessed drive cables | Baumüller, SpeedTec Harnessed drive cables | Baumüller, SpeedTec
Baumüller, Baumüller,
SpeedTec SpeedTec
PVC/PUR PVC/PUR

* Technical information on the cable quality (Code 01-31):  Page 578-581 * Technical information on the cable quality (Code 01-31):  Page 578-581

Cable quality Part No. Number of cores and conductor Ø R min. Cable quality Part No. Number of cores and conductor Ø R min.
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Baumüller Servo cables, SpeedTec Baumüller Servo cables, SpeedTec

21 A Basic cable, SpeedTec 21 A Extension cable, SpeedTec

447693 447686
PVC O.I. 04 MAT9750290 (4G2.5+2x(2x1.5)C)C 16.0 10 PVC O.I. 04 MAT9750298 (4G2.5+2x(2x1.5)C)C 16.0 10
PVC M.I. 05 MAT9295117 (4G2.5+2x(2x1.5)C)C 17.0 7.5 PVC M.I. 05 MAT9297081 (4G2.5+2x(2x1.5)C)C 17.0 7.5
PUR O.I. 06 MAT9850300 (4G2.5+2x(2x1.5)C)C 15.5 10 PUR O.I. 06 MAT9880208 (4G2.5+2x(2x1.5)C)C 15.5 10
PUR M.I. 07 MAT9296117 (4G2.5+2x(2x1.5)C)C 16.0 7.5 PUR M.I. 07 MAT9298081 (4G2.5+2x(2x1.5)C)C 16.0 7.5
447694
PVC O.I. 04 MAT9750291 (4G2.5+2x(2x1.5)C)C 16.0 10 28 A Basic cable, SpeedTec
PVC M.I. 05 MAT9295118 (4G2.5+2x(2x1.5)C)C 17.0 7.5
PUR O.I. 06 MAT9880201 (4G2.5+2x(2x1.5)C)C 15.5 10 448063
PUR M.I. 07 MAT9296118 (4G2.5+2x(2x1.5)C)C 16.0 7.5 PVC O.I. 04 MAT9750299 (4G4.0+2x(2x1.5)C)C 17.0 10
447695 PVC M.I. 05 MAT9295125 (4G4.0+2x(2x1.5)C)C 18.0 7.5
PVC O.I. 04 MAT9750292 (4G2.5+2x(2x1.5)C)C 16.0 10 PUR O.I. 06 MAT9880209 (4G4.0+2x(2x1.5)C)C 16.5 10
PVC M.I. 05 MAT9295119 (4G2.5+2x(2x1.5)C)C 17.0 7.5 PUR M.I. 07 MAT9296125 (4G4.0+2x(2x1.5)C)C 17.5 7.5
PUR O.I. 06 MAT9880202 (4G2.5+2x(2x1.5)C)C 15.5 10 448064
PUR M.I. 07 MAT9296119 (4G2.5+2x(2x1.5)C)C 16.0 7.5 PVC O.I. 04 MAT9750300 (4G4.0+2x(2x1.5)C)C 17.0 10
447696 PVC M.I. 05 MAT9295126 (4G4.0+2x(2x1.5)C)C 18.0 7.5
PVC O.I. 04 MAT9750293 (4G2.5+2x(2x1.5)C)C 16.0 10 PUR O.I. 06 MAT9880210 (4G4.0+2x(2x1.5)C)C 16.5 10
PVC M.I. 05 MAT9295120 (4G2.5+2x(2x1.5)C)C 17.0 7.5 PUR M.I. 07 MAT9296126 (4G4.0+2x(2x1.5)C)C 17.5 7.5
PUR O.I. 06 MAT9880203 (4G2.5+2x(2x1.5)C)C 15.5 10 448065
PUR M.I. 07 MAT9296120 (4G2.5+2x(2x1.5)C)C 16.0 7.5 PVC O.I. 04 MAT9780201 (4G4.0+2x(2x1.5)C)C 17.0 10
447697 PVC M.I. 05 MAT9295127 (4G4.0+2x(2x1.5)C)C 18.0 7.5
PVC O.I. 04 MAT9750294 (4G2.5+2x(2x1.5)C)C 16.0 10 PUR O.I. 06 MAT9880211 (4G4.0+2x(2x1.5)C)C 16.5 10
PVC M.I. 05 MAT9295121 (4G2.5+2x(2x1.5)C)C 17.0 7.5 PUR M.I. 07 MAT9296127 (4G4.0+2x(2x1.5)C)C 17.5 7.5
PUR O.I. 06 MAT9880204 (4G2.5+2x(2x1.5)C)C 15.5 10 448066
PUR M.I. 07 MAT9296121 (4G2.5+2x(2x1.5)C)C 16.0 7.5 PVC O.I. 04 MAT9780202 (4G4.0+2x(2x1.5)C)C 17.0 10
447699 PVC M.I. 05 MAT9295128 (4G4.0+2x(2x1.5)C)C 18.0 7.5
PVC O.I. 04 MAT9750295 (4G2.5+2x(2x1.5)C)C 16.0 10 PUR O.I. 06 MAT9880212 (4G4.0+2x(2x1.5)C)C 16.5 10
PVC M.I. 05 MAT9295122 (4G2.5+2x(2x1.5)C)C 17.0 7.5 PUR M.I. 07 MAT9296128 (4G4.0+2x(2x1.5)C)C 17.5 7.5
PUR O.I. 06 MAT9880205 (4G2.5+2x(2x1.5)C)C 15.5 10 448067
PUR M.I. 07 MAT9296122 (4G2.5+2x(2x1.5)C)C 16.0 7.5 PVC O.I. 04 MAT9780203 (4G4.0+2x(2x1.5)C)C 17.0 10
448060 PVC M.I. 05 MAT9295129 (4G4.0+2x(2x1.5)C)C 18.0 7.5
PVC O.I. 04 MAT9750296 (4G2.5+2x(2x1.5)C)C 16.0 10 PUR O.I. 06 MAT9880213 (4G4.0+2x(2x1.5)C)C 16.5 10
PVC M.I. 05 MAT9295123 (4G2.5+2x(2x1.5)C)C 17.0 7.5 PUR M.I. 07 MAT9296129 (4G4.0+2x(2x1.5)C)C 17.5 7.5
PUR O.I. 06 MAT9880206 (4G2.5+2x(2x1.5)C)C 15.5 10 448069
PUR M.I. 07 MAT9296123 (4G2.5+2x(2x1.5)C)C 16.0 7.5 PVC O.I. 04 MAT9780204 (4G4.0+2x(2x1.5)C)C 17.0 10
448061 PVC M.I. 05 MAT9295130 (4G4.0+2x(2x1.5)C)C 18.0 7.5
PVC O.I. 04 MAT9750297 (4G2.5+2x(2x1.5)C)C 16.0 10 PUR O.I. 06 MAT9880214 (4G4.0+2x(2x1.5)C)C 16.5 10
PVC M.I. 05 MAT9295124 (4G2.5+2x(2x1.5)C)C 17.0 7.5 PUR M.I. 07 MAT9296130 (4G4.0+2x(2x1.5)C)C 17.5 7.5
PUR O.I. 06 MAT9880207 (4G2.5+2x(2x1.5)C)C 15.5 10
PUR M.I. 07 MAT9296124 (4G2.5+2x(2x1.5)C)C 16.0 7.5

Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
®
®
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
®
®
