Page 659 - ASEAN Chainflex Catalogue 2023
P. 659
Harnessed drive cables | Beckhoff Harnessed drive cables | Beckhoff
Beckhoff Beckhoff
PVC/PUR PVC/PUR
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor Ø R min. Cable quality Part No. Number of cores and conductor Ø R min.
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Beckhoff Motor cables Beckhoff Servo cables
Basic cable Basic cable
ZK4500-8015-xxx ZK4000-2711-xxxx
PUR O.I. 06 MAT9850314 (4G4.0+(2x1.0)C+(2xAWG22)C)C 16.0 10 PVC O.I. 04 MAT9750307 (4G1.5+(2x1.5)C) 12.5 10
ZK4500-8024-xxx PVC M.I. 05 MAT9371007 (4G1.5+(2x1.5)C) 13.0 7.5
PVC O.I. 04 MAT9750312 (4G2.5+(2x1.0)C+(2xAWG22)C)C 15.0 10 PUR O.I. 06 MAT9850307 (4G1.5+(2x1.5)C) 12.5 10
PUR O.I. 06 MAT9850312 (4G2.5+(2x1.0)C+(2xAWG22)C)C 15.0 10 PUR M.I. 07 MAT9372007 (4G1.5+(2x1.5)C) 13.0 7.5
Basic cable Basic cable
ZK4501-8024-xxx ZK4500-0023-xxxx
PVC O.I. 04 MAT9750313 (4G2.5+(2x1.0)C+(2xAWG22)C)C 15.0 10 PVC O.I. 04 MAT9750301 (4G1.5+2x(2x0.75)C)C 13.5 10
PUR O.I. 06 MAT9850313 (4G2.5+(2x1.0)C+(2xAWG22)C)C 15.0 10 PVC M.I. 05 MAT9371001 (4G1.5+2x(2x0.75)C)C 14.5 7.5
PUR O.I. 06 MAT9850301 (4G1.5+2x(2x0.75)C)C 13.5 10
Basic cable PUR M.I. 07 MAT9372001 (4G1.5+2x(2x0.75)C)C 14.5 7.5
ZK4530-8110-xxxx Basic cable
PVC 14 MAT9381006 (4x(2x0.25))C 7.5 7.5
PUR 15 MAT9382006 (4x(2x0.25))C 7.5 7.5 ZK4500-0024-xxxx
PVC O.I. 04 MAT9750302 (4G2.5+2x(2x1.5)C)C 16.0 10
Extension cable PVC M.I. 05 MAT9371002 (4G2.5+2x(2x1.5)C)C 17.0 7.5
PUR O.I. 06 MAT9850302 (4G2.5+2x(2x1.5)C)C 16.0 10
ZK4704-0411-xxxx PUR M.I. 07 MAT9372002 (4G2.5+2x(2x1.5)C)C 16.0 7.5
PVC M.I. 05 MAT9371008 (4G0.75+(2x0.5)C)C 11.0 7.5
PUR M.I. 07 MAT9750316 (4G0.75+(2x0.5)C)C 11.5 7.5 Extension cable
Beckhoff Servo cables
ZK4501-0023-xxxx
Basic cable PVC O.I. 04 MAT9750303 (4G1.5+2x(2x0.75)C)C 13.5 10
PVC M.I. 05 MAT9371003 (4G1.5+2x(2x0.75)C)C 14.5 7.5
ZK4000-2111-xxxx PUR O.I. 06 MAT9850303 (4G1.5+2x(2x0.75)C)C 13.5 10
PVC O.I. 04 MAT9750305 (4G1.5+(2x1.5)C) 12.5 10 PUR M.I. 07 MAT9372003 (4G1.5+2x(2x0.75)C)C 14.5 7.5
PVC M.I. 05 MAT9371005 (4G1.5+(2x1.5)C) 13.0 7.5
PUR O.I. 06 MAT9850305 (4G1.5+(2x1.5)C) 12.5 10 Extension cable
PUR M.I. 07 MAT9372005 (4G1.5+(2x1.5)C) 13.0 7.5
ZK4501-0024-xxxx
Basic cable PVC O.I. 04 MAT9750304 (4G2.5+2x(2x1.5)C)C 16.0 10
PVC M.I. 05 MAT9371004 (4G2.5+2x(2x1.5)C)C 17.0 7.5
ZK4000-2112-xxxx PUR O.I. 06 MAT9850304 (4G2.5+2x(2x1.5)C)C 16.0 10
PVC O.I. 04 MAT9750306 (4G2.5+(2x1.5)C)C 14.0 10 PUR M.I. 07 MAT9372004 (4G2.5+2x(2x1.5)C)C 16.0 7.5
PVC M.I. 05 MAT9371006 (4G2.5+(2x1.5)C)C 14.5 7.5
PUR O.I. 06 MAT9850306 (4G2.5+(2x1.5)C)C 14.0 10
PUR M.I. 07 MAT9372006 (4G2.5+(2x1.5)C)C 14.5 7.5
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
652 EPLAN download, configurators www.igus-asean.com/readycable 100 % digitally tested ... to your required length, no minimum order quantity ... 36-month chainflex guarantee 653
®
