Harnessed drive cables | Parker Harnessed drive cables | Parker
Parker Parker
PVC/PUR PVC/PUR/TPE
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and Ø R min. Cable quality Part No. Number of cores and Ø R min.
conductor nominal cross section conductor nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Parker Motor cables Parker Resolver cables
Basic cable Basic cable
iMOK42 iREK32
PVC O.I. 04 MAT9752255 (4G1.5+(2x1.5)C) 12.5 10 PVC 14 MAT9722211 (4x(2x0.25))C 7.5 7.5
PVC M.I. 05 MAT9752205 (4G2.5+(2x1.5)C)C 14.5 7.5 PUR 15 MAT9822211 (4x(2x0.25))C 7.5 7.5
PUR O.I. 06 MAT9852255 (4G1.5+(2x1.5)C) 12.5 10 TPE H* 16 MAT9922211 (4x(2x0.25))C 8.5 6.8
PUR M.I. 07 MAT9852205 (4G1.5+(2x1.5)C) 13.0 7.5 iREK33
iMOK43 PVC 14 MAT9722212 (4x(2x0.25))C 7.5 7.5
PVC O.I. 04 MAT9752257 (4G2.5+(2x1.5)C)C 14.0 10 PUR 15 MAT9822212 (4x(2x0.25))C 7.5 7.5
PUR O.I. 06 MAT9852257 (4G2.5+(2x1.5)C)C 14.0 10 TPE H* 16 MAT9922212 (4x(2x0.25))C 8.5 6.8
PUR O.I. 06 MAT9752207 (4G2.5+(2x1.5)C)C 14.5 7.5 iREK41
PUR M.I. 07 MAT9852207 (4G2.5+(2x1.5)C)C 14.5 7.5 PVC 14 MAT9722210 (4x(2x0.25))C 7.5 7.5
iMOK44 PUR 15 MAT9822210 (4x(2x0.25))C 7.5 7.5
PVC O.I. 04 MAT9752256 (4G1.5+(2x1.5)C) 12.5 10 TPE H* 16 MAT9922210 (4x(2x0.25))C 8.5 6.8
PUR O.I. 06 MAT9852256 (4G1.5+(2x1.5)C) 12.5 10 iREK42
PUR O.I. 06 MAT9752206 (4G1.5+(2x1.5)C) 13.0 7.5 PVC 14 MAT9722209 (4x(2x0.25))C 7.5 7.5
PUR M.I. 07 MAT9852206 (4G1.5+(2x1.5)C) 13.0 7.5 PUR 15 MAT9822209 (4x(2x0.25))C 7.5 7.5
iMOK45 TPE H* 16 MAT9922209 (4x(2x0.25))C 8.5 6.8
PVC O.I. 04 MAT9752258 (4G2.5+(2x1.5)C)C 14.0 10
PUR O.I. 06 MAT9852258 (4G2.5+(2x1.5)C)C 14.0 10
PUR O.I. 06 MAT9752208 (4G2.5+(2x1.5)C)C 14.5 7.5
PUR M.I. 07 MAT9852208 (4G2.5+(2x1.5)C)C 14.5 7.5
iMOK54
PVC O.I. 04 MAT9752252 (4G1.5+(2x1.5)C) 12.5 10
PVC M.I. 05 MAT9752202 (4G1.5+(2x1.5)C) 13.0 7.5
PUR O.I. 06 MAT9852252 (4G1.5+(2x1.5)C) 12.5 10
PUR M.I. 07 MAT9852202 (4G1.5+(2x1.5)C) 13.0 7.5
iMOK55
PVC O.I. 04 MAT9752251 (4G1.5+(2x1.5)C) 12.5 10
PVC M.I. 05 MAT9752201 (4G1.5+(2x1.5)C) 13.0 7.5
PUR O.I. 06 MAT9852251 (4G1.5+(2x1.5)C) 12.5 10
PUR M.I. 07 MAT9852201 (4G1.5+(2x1.5)C) 13.0 7.5
iMOK56
PVC O.I. 04 MAT9752253 (4G2.5+(2x1.5)C)C 14.0 10
PVC M.I. 05 MAT9752203 (4G2.5+(2x1.5)C)C 14.5 7.5
PUR O.I. 06 MAT9852253 (4G2.5+(2x1.5)C)C 14.0 10
PUR M.I. 07 MAT9852203 (4G2.5+(2x1.5)C)C 14.5 7.5
iMOK57
PVC O.I. 04 MAT9752254 (4G2.5+(2x1.5)C)C 14.0 10
PUR O.I. 06 MAT9852254 (4G2.5+(2x1.5)C)C 14.0 10
PUR O.I. 06 MAT9752204 (4G2.5+(2x1.5)C)C 14.5 7.5
PUR M.I. 07 MAT9852204 (4G2.5+(2x1.5)C)C 14.5 7.5
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
®
®
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
®
®
