Page 749 - ASEAN Chainflex Catalogue 2023
P. 749
Harnessed drive cables | SEW Harnessed drive cables | SEW
SEW SEW
PVC/PUR/TPE EPLAN macros available online Page 582/583 PVC/PUR EPLAN macros available online Page 582/583
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor Ø R min. Cable quality Part No. Number of cores and conductor Ø R min.
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
SEW Servo cables SEW Servo cables
1335 0250
Connection cable PVC M.I. 05 MAT9751436 (4G16+2x(2x1.5)C)C 26.5 7.5
PUR O.I. 06 MAT9851418 (4G16+2x(2x1.5)C)C 26.0 10
1333 1221 PUR M.I. 07 MAT9851436 (4G16+(2x1.5)C)C 24.0 7.5
PVC O.I. 04 MAT9751473 (4G1.5+(2x1.5)C) 12.5 10 1335 4302
PVC M.I. 05 MAT9751474 (4G1.5+(2x1.5)C) 13.0 7.5 PUR O.I. 27 MAT9851419 (4G1.5+(3x1.0)C)C 12.0 10
PUR O.I. 06 MAT9851473 (4G1.5+(2x1.5)C) 12.5 10 1335 4310
PUR M.I. 07 MAT9851474 (4G1.5+(2x1.5)C) 13.0 7.5 PVC O.I. 04 MAT9751420 (4G2.5+2x(2x1.5)C)C 16.0 10
TPE H* 31 MAT9951473 (4G1.5+(2x1.5)C) 13.0 6.8 PVC M.I. 05 MAT9751438 (4G2.5+2x(2x1.5)C)C 17.0 7.5
1333 2155 PUR O.I. 06 MAT9851420 (4G2.5+2x(2x1.5)C)C 16.0 10
PVC O.I. 04 MAT9751471 (4G2.5+(2x1.5)C)C 14.0 10 PUR M.I. 07 MAT9851438 (4G2.5+2x(2x1.5)C)C 16.0 7.5
PVC M.I. 05 MAT9751472 (4G2.5+(2x1.5)C)C 14.5 7.5 1335 4329
PUR O.I. 06 MAT9851471 (4G2.5+(2x1.5)C)C 14.0 10 PVC O.I. 04 MAT9751421 (4G4.0+2x(2x1.5)C)C 17.0 10
PUR M.I. 07 MAT9851472 (4G2.5+(2x1.5)C)C 14.5 7.5 PVC M.I. 05 MAT9751439 (4G4.0+2x(2x1.5)C)C 18.0 7.5
TPE H* 31 MAT9951471 (4G2.5+(2x1.5)C)C 14.0 6.8 PUR O.I. 06 MAT9851421 (4G4.0+2x(2x1.5)C)C 17.0 10
PUR M.I. 07 MAT9851439 (4G4.0+2x(2x1.5)C)C 17.5 7.5
Connection cable 1335 4388
PUR O.I. 27 MAT9851413 (4G1.5+(3x1.0)C)C 12.0 10
1335 0153 1335 4396
PVC O.I. 04 MAT9751422 (4G6.0+2x(2x1.5)C)C 19.0 10 PUR O.I. 27 MAT9851479 (4G2.5+(3x1.0)C)C 13.5 10
PVC M.I. 05 MAT9751440 (4G6.0+2x(2x1.5)C)C 21.0 7.5
PUR O.I. 06 MAT9851422 (4G6.0+2x(2x1.5)C)C 19.0 10 Extension cable (Amphenol)
PUR M.I. 07 MAT9851440 (4G6.0+2x(2x1.5)C)C 19.5 7.5
1335 0161 0199 2007
PVC M.I. 05 MAT9751441 (4G10+2x(2x1.5)C)C 23.0 7.5 PVC O.I. 04 MAT9751406 (4G1.5+2x(2x0.75)C)C 13.5 10
PUR O.I. 06 MAT9851423 (4G10+2x(2x1.5)C)C 22.5 10 PVC M.I. 05 MAT9411001 (4G1.5+2x(2x0.75)C)C 14.5 7.5
PUR M.I. 07 MAT9851441 (4G10+2x(2x1.5)C)C 22.5 7.5 PUR O.I. 06 MAT9851407 (4G1.5+2x(2x0.75)C)C 13.5 10
1335 0188 PUR M.I. 07 MAT9401001 (4G1.5+2x(2x0.75)C)C 14.5 7.5
PVC M.I. 05 MAT9751442 (4G16+2x(2x1.5)C)C 26.5 7.5 0199 2023
PUR O.I. 06 MAT9851424 (4G16+2x(2x1.5)C)C 26.0 10 PVC O.I. 04 MAT9751407 (4G2.5+2x(2x1.5)C)C 16.0 10
PUR M.I. 07 MAT9851442 (4G16+2x(2x1.5)C)C 26.0 7.5 PVC M.I. 05 MAT9411002 (4G2.5+2x(2x1.5)C)C 17.0 7.5
1335 0234 PUR O.I. 06 MAT9851408 (4G2.5+2x(2x1.5)C)C 16.0 10
PVC O.I. 04 MAT9751416 (4G6.0+(2x1.5)C)C 16.5 10 PUR M.I. 07 MAT9401002 (4G2.5+2x(2x1.5)C)C 16.0 7.5
PVC M.I. 05 MAT9751434 (4G6.0+(2x1.5)C)C 18.0 7.5 0199 204X
PUR O.I. 06 MAT9851416 (4G6.0+(2x1.5)C)C 16.5 10 PVC O.I. 04 MAT9751408 (4G4.0+2x(2x1.5)C)C 17.0 10
PUR M.I. 07 MAT9851434 (4G6.0+(2x1.5)C)C 17.5 7.5 PVC M.I. 05 MAT9411003 (4G4.0+2x(2x1.5)C)C 18.0 7.5
1335 0242 PUR O.I. 06 MAT9851409 (4G4.0+2x(2x1.5)C)C 17.0 10
PVC M.I. 05 MAT9751435 (4G10+(2x1.5)C)C 21.5 7.5 PUR M.I. 07 MAT9401003 (4G4.0+2x(2x1.5)C)C 17.5 7.5
PUR O.I. 06 MAT9851417 (4G10+(2x1.5)C)C 21.0 10 0199 2066
PUR M.I. 07 MAT9851435 (4G10+(2x1.5)C)C 21.0 7.5 PVC O.I. 04 MAT9751409 (4G6.0+2x(2x1.5)C)C 19.0 10
PVC M.I. 05 MAT9411004 (4G6.0+2x(2x1.5)C)C 21.0 7.5
PUR O.I. 06 MAT9851410 (4G6.0+2x(2x1.5)C)C 19.0 10
PUR M.I. 07 MAT9401004 (4G6.0+2x(2x1.5)C)C 19.5 7.5
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
742 EPLAN download, configurators www.igus-asean.com/readycable 100 % digitally tested ... to your required length, no minimum order quantity ... 36-month chainflex guarantee 743
®
