Harnessed drive cables | SEW Harnessed drive cables | SEW
SEW SEW
PVC/PUR/TPE EPLAN macros available online Page 582/583 PVC/PUR/TPE EPLAN macros available online Page 582/583
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor Ø R min. Cable quality Part No. Number of cores and conductor Ø R min.
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
SEW Hybrid servo cables SEW Control cables
Connection cable
Basic cable
0199 560x
0186 725 3 PVC, oil-res. 19 MAT9711401 3G1.0 6.5 6.8
PUR O.I. 27 MAT9851443 4G1.5+(2x0.75)C+(3x0.75)C 14.0 10 PUR 21 MAT9811401 3G1.0 6.5 6.8
0187 889 5 TPE F 25 MAT9911401 3G1.0 6.5 5
PUR O.I. 27 MAT9851456 (7x2.5+(2x0.75)C)C 20.0 10 SEW Encoder cables
0593 278 5
PUR O.I. 27 MAT9851449 (7x2.5+(2x0.75)C)C 20.0 10 Connection cable
0593 755 8
PUR O.I. 27 MAT9851451 (7x2.5+(2x0.75)C)C 20.0 10 0198 9308
0816 208 5 PUR M.I. 10 MAT9841404 (3x(2x0.25))C 7.5 7.5
PUR O.I. 27 MAT9851454 (7x2.5+(2x0.75)C)C 20.0 10 0199 3194
0816 325 1 PUR M.I. 10 MAT9841401 (5x(2x0.25))C 8.5 7.5
PUR O.I. 27 MAT9851450 (7x2.5+(2x0.75)C)C 20.0 10 0199 4875
0816 326 X PVC 08 MAT9741401 (5x(2x0.25))C 8.0 10
PUR O.I. 27 MAT9851452 (7x2.5+(2x0.75)C)C 20.0 10 0595 1518
0817 886 0 PVC 08 MAT9741408 (6x(2x0.25))C 8.5 10
PUR O.I. 27 MAT9851457 (7x2.5+(2x0.75)C)C 20.0 10 PUR M.I. 10 MAT9841408 (6x(2x0.25))C 9.0 7.5
0817 887 9 TPE H* 16 MAT9941408 (6x(2x0.25))C 10.0 6.8
PUR O.I. 27 MAT9851455 (7x2.5+(2x0.75)C)C 20.0 10 1332 4551
0817 888 7 PVC 08 MAT9741403 (6x(2x0.25))C 8.5 10
PUR O.I. 27 MAT9851458 (7x2.5+(2x0.75)C)C 20.0 10 PUR M.I. 10 MAT9841403 (6x(2x0.25))C 9.0 7.5
0817 948 4 1332 7437
PUR O.I. 27 MAT9851453 (7x2.5+(2x0.75)C)C 20.0 10 PVC 08 MAT9741402 (5x(2x0.25))C 8.0 10
PUR M.I. 10 MAT9841402 (5x(2x0.25))C 8.5 7.5
Connection cable
Extension cable
2812 3743
PUR O.I. 28 New MAT9851482 (4G1.5+2x(2x1.0)C+HF50-0.9/2.95)C 15.5 10 0199 5405
2812 3751 PVC 08 MAT9741406 (6x(2x0.25))C 8.5 10
PUR O.I. 28 New MAT9851484 (4G2.5+2x(2x1.0)C+HF50-0.9/2.95)C 16.5 10 PUR M.I. 10 MAT9841406 (6x(2x0.25))C 9.0 7.5
0199 5413
Extension cable PVC 08 MAT9741405 (5x(2x0.25))C 8.0 10
PUR M.I. 10 MAT9841405 (5x(2x0.25))C 8.5 7.5
2812 3859 0593 9682
PUR O.I. 28 New MAT9851483 (4G1.5+2x(2x1.0)C+HF50-0.9/2.95)C 15.5 10 PVC 08 MAT9741407 (5x(2x0.25))C 8.0 10
2812 3867 PUR M.I. 10 MAT9841407 (5x(2x0.25))C 8.5 7.5
PUR O.I. 28 New MAT9851485 (4G2.5+2x(2x1.0)C+HF50-0.9/2.95)C 16.5 10
Connection cable
1811 8119
PUR O.I. 27 MAT9851464 (7x1.5+(2x0.75)C)C 16.0 10 Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
ASEAN2023 ASEAN2023 * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
