Harnessed drive cables | Siemens Harnessed drive cables | Siemens
Siemens Siemens
PVC/PUR/TPE EPLAN macros available online Page 582/583 PVC/PUR/TPE EPLAN macros available online Page 582/583
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor nomi- Ø R min. Cable quality Part No. Number of cores and conductor nomi- Ø R min.
nal cross section nal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Siemens Power cables Siemens Power cables
Basic cable Basic cable
6FX_002-5CL02 6FX_002-5CS12
PVC M.I. 01 MAT9761572 (4G1.5)C 10.0 7.5 PVC M.I. 01 MAT9761503 (4G2.5)C 11.5 7.5
PUR O.I. 06 MAT98615126 (4G1.5)C 9.0 10 PUR O.I. 06 MAT9861530 (4G2.5)C 10.5 10
PUR M.I. 07 MAT98615127 (4G1.5)C 11.0 7.5 PUR M.I. 07 MAT9861529 (4G2.5)C 12.5 7.5
TPE F 02 MAT9961563 (4G1.5)C 10.0 7.5 TPE F 02 MAT9961503 (4G2.5)C 11.5 7.5
6FX_002-5CL12
PVC M.I. 01 MAT9761573 (4G2.5)C 11.5 7.5 Basic cable
PUR O.I. 06 MAT98615128 (4G2.5)C 10.5 10
PUR M.I. 07 MAT98615129 (4G2.5)C 12.5 7.5 6FX_002-5CS13
TPE F 02 MAT9961564 (4G2.5)C 11.5 7.5 PVC M.I. 01 MAT9761504 (4G10)C 18.5 7.5
PUR O.I. 06 MAT9861531 (4G10)C 17.0 10
Basic cable TPE F 02 MAT9961504 (4G10)C 18.5 7.5
6FX_002-5CS21
6FX_002-5CS01 PVC M.I. 01 MAT9150021 (4G1.5)C 10.0 7.5
PVC M.I. 01 MAT9150020 (4G1.5)C 10.0 7.5 PUR O.I. 06 MAT9861513 (4G1.5)C 9.0 10
PUR O.I. 06 MAT9861512 (4G1.5)C 10.0 10 PUR M.I. 07 MAT9861502 (4G1.5)C 11.0 7.5
PUR M.I. 07 MAT9861501 (4G1.5)C 11.0 7.5 TPE F 02 MAT9050021 (4G1.5)C 10.0 7.5
TPE F 02 MAT9050020 (4G1.5)C 10.0 7.5
Basic cable
Basic cable
6FX_002-5CS23
6FX_002-5CS02 PVC M.I. 01 MAT9761515 (4G16)C 23.0 7.5
PVC M.I. 01 MAT9761501 (4G1.5)C 10.0 7.5 PUR O.I. 06 MAT9861547 (4G16)C 20.5 10
PUR O.I. 06 MAT9861526 (4G1.5)C 9.0 10 TPE F 02 MAT9961515 (4G16)C 23.0 7.5
PUR M.I. 07 MAT9861525 (4G1.5)C 11.0 7.5 6FX_002-5CS24
TPE F 02 MAT9961501 (4G1.5)C 10.0 7.5 PVC M.I. 01 MAT9761570 (4G16)C 23.0 7.5
PUR O.I. 06 MAT98615125 (4G16)C 20.5 10
Basic cable TPE F 02 MAT9961561 (4G16)C 23.0 7.5
TPE H* 03 MAT9961562 (4G16)C 23.0 7.5
6FX_002-5CS11
PVC M.I. 01 MAT9761502 (4G2.5)C 11.5 7.5 Basic cable
PUR O.I. 06 MAT9861528 (4G2.5)C 10.5 10
PUR M.I. 07 MAT9861527 (4G2.5)C 12.5 7.5 6FX_002-5CS31
TPE F 02 MAT9961502 (4G2.5)C 11.5 7.5 PVC M.I. 01 MAT9150022 (4G2.5)C 11.5 7.5
PUR O.I. 06 MAT9861514 (4G2.5)C 10.5 10
PUR M.I. 07 MAT9861503 (4G2.5)C 12.5 7.5
TPE F 02 MAT9050022 (4G2.5)C 11.5 7.5
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
