Page 765 - ASEAN Chainflex Catalogue 2023
P. 765
Harnessed drive cables | Siemens Harnessed drive cables | Siemens
Siemens Siemens
PVC/PUR/TPE EPLAN macros available online Page 582/583 PVC/PUR/TPE EPLAN macros available online Page 582/583
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor nomi- Ø R min. Cable quality Part No. Number of cores and conductor nomi- Ø R min.
nal cross section nal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Siemens Servo cables Siemens Servo cables
6FX_002-5DG21
Basic cable PVC O.I. 04 MAT9751531 (4G1.5+(2x1.5)C) 12.5 10
PVC M.I. 05 MAT9751530 (4G1.5+(2x1.5)C) 13.0 7.5
6FX_002-5DA43
PVC M.I. 05 MAT9160010 (4G35+(2x1.5)C)C 33.5 7.5 Basic cable
PUR M.I. 07 MAT9060010 (4G35+(2x1.5)C)C 32.0 7.5
PUR O.I. 06 MAT9851543 (4G1.5+(2x1.5)C) 12.5 10
Basic cable PUR M.I. 07 MAT9851542 (4G1.5+(2x1.5)C) 13.0 7.5
6FX_002-5DA51 Basic cable
PVC O.I. 04 MAT9751506 (4G6.0+(2x1.5)C)C 16.5 10
PVC M.I. 05 MAT9160006 (4G6.0+(2x1.5)C)C 18.0 7.5 6FX_002-5DG23
PUR O.I. 06 MAT9851506 (4G6.0+(2x1.5)C)C 16.5 10 PUR O.I. 06 MAT9851557 (4G16+(2x1.5)C)C 24.0 10
PUR M.I. 07 MAT9060006 (4G6.0+(2x1.5)C)C 17.5 7.5 PUR M.I. 07 MAT9851556 (4G16+(2x1.5)C)C 24.0 7.5
6FX_002-5DA61 6FX_002-5DG31
PVC M.I. 05 MAT9160007 (4G10+(2x1.5)C)C 21.5 7.5 PVC O.I. 04 MAT9751535 (4G2.5+(2x1.5)C)C 14.0 10
PUR O.I. 06 MAT9851507 (4G10+(2x1.5)C)C 21.0 10 PVC M.I. 05 MAT9751534 (4G2.5+(2x1.5)C)C 14.5 7.5
PUR M.I. 07 MAT9060007 (4G10+(2x1.5)C)C 21.0 7.5 PUR O.I. 06 MAT9851547 (4G2.5+(2x1.5)C)C 14.0 10
PUR M.I. 07 MAT9851546 (4G2.5+(2x1.5)C)C 14.5 7.5
Basic cable
Basic cable
6FX_002-5DG01
PVC O.I. 04 MAT9751529 (4G1.5+(2x1.5)C) 12.5 10 6FX_002-5DG33
PVC M.I. 05 MAT9751528 (4G1.5+(2x1.5)C) 13.0 7.5 PUR M.I. 07 MAT9851558 (4G25+(2x1.5)C)C 28.0 7.5
PUR O.I. 06 MAT9851541 (4G1.5+(2x1.5)C) 12.5 10 6FX_002-5DG41
PUR M.I. 07 MAT9851540 (4G1.5+(2x1.5)C) 13.0 7.5 PVC O.I. 04 MAT9751537 (4G4.0+(2x1.5)C)C 15.0 10
PVC M.I. 05 MAT9751536 (4G4.0+(2x1.5)C)C 16.0 7.5
Basic cable PUR O.I. 06 MAT9851549 (4G4.0+(2x1.5)C)C 15.0 10
PUR M.I. 07 MAT9851548 (4G4.0+(2x1.5)C)C 16.0 7.5
6FX_002-5DG11
PVC O.I. 04 MAT9751533 (4G2.5+(2x1.5)C)C 14.0 10 Basic cable
PVC M.I. 05 MAT9751532 (4G2.5+(2x1.5)C)C 14.5 7.5
PUR O.I. 06 MAT9851545 (4G2.5+(2x1.5)C)C 14.0 10 6FX_002-5DG43
PUR M.I. 07 MAT9851544 (4G2.5+(2x1.5)C)C 14.5 7.5 PUR M.I. 07 MAT9851559 (4G35+(2x1.5)C)C 32.0 7.5
6FX_002-5DG51
Basic cable PVC O.I. 04 MAT9751539 (4G6.0+(2x1.5)C)C 16.5 10
PVC M.I. 05 MAT9751538 (4G6.0+(2x1.5)C)C 18.0 7.5
6FX_002-5DG13 PUR O.I. 06 MAT9851551 (4G6.0+(2x1.5)C)C 16.5 10
PVC M.I. 05 MAT9751541 (4G10+(2x1.5)C)C 21.5 7.5 PUR M.I. 07 MAT9851550 (4G6.0+(2x1.5)C)C 17.5 7.5
PUR O.I. 06 MAT9851555 (4G10+(2x1.5)C)C 21.0 10
PUR M.I. 07 MAT9851554 (4G10+(2x1.5)C)C 21.0 7.5
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
®
®
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
758 EPLAN download, configurators www.igus-asean.com/readycable 100 % digitally tested ... to your required length, no minimum order quantity ... 36-month chainflex guarantee 759
®
