Harnessed drive cables | Siemens Harnessed drive cables | Siemens
Siemens Siemens
PVC/PUR/TPE EPLAN macros available online Page 582/583 PVC/PUR EPLAN macros available online Page 582/583
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor nomi- Ø R min. Cable quality Part No. Number of cores and conductor nomi- Ø R min.
nal cross section nal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Siemens Servo cables Siemens Servo cables
Basic cable Basic cable
6FX_002-5DG61 6FX_002-5DN46
PVC M.I. 05 MAT9751540 (4G10+(2x1.5)C)C 21.5 7.5 PVC O.I. 04 MAT97515113 (4G4.0+(2x1.5)C)C 15.0 10
PUR O.I. 06 MAT9851553 (4G10+(2x1.5)C)C 21.0 10 PVC M.I. 05 MAT97515114 (4G4.0+(2x1.5)C)C 16.0 7.5
PUR M.I. 07 MAT9851552 (4G10+(2x1.5)C)C 21.0 7.5 PUR O.I. 06 MAT98515133 (4G4.0+(2x1.5)C)C 15.0 10
PUR M.I. 07 MAT98515134 (4G4.0+(2x1.5)C)C 16.0 7.5
Basic cable
Basic cable
6FX_002-5DN06
PVC O.I. 04 MAT97515103 (4G1.5+(2x1.5)C) 12.5 10 6FX_002-5DN56
PVC M.I. 05 MAT97515102 (4G1.5+(2x1.5)C) 13.0 7.5 PVC O.I. 04 MAT97515119 (4G6.0+(2x1.5)C)C 16.5 10
PUR O.I. 06 MAT98515122 (4G1.5+(2x1.5)C) 12.5 10 PVC M.I. 05 MAT97515120 (4G6.0+(2x1.5)C)C 18.0 7.5
PUR M.I. 07 MAT98515123 (4G1.5+(2x1.5)C) 13.0 7.5 PUR O.I. 06 MAT98515139 (4G6.0+(2x1.5)C)C 16.5 10
PUR M.I. 07 MAT98515140 (4G6.0+(2x1.5)C)C 17.5 7.5
Basic cable
Basic cable
6FX_002-5DN16
PVC O.I. 04 MAT97515108 (4G2.5+(2x1.5)C)C 14.0 10 6FX_002-5DS01
PVC M.I. 05 MAT97515109 (4G2.5+(2x1.5)C)C 14.5 7.5 PVC O.I. 04 MAT9751507 (4G1.5+(2x1.5)C) 12.5 10
PUR O.I. 06 MAT98515129 (4G2.5+(2x1.5)C)C 14.0 10 PVC M.I. 05 MAT9160020 (4G1.5+(2x1.5)C) 13.0 7.5
PUR M.I. 07 MAT98515128 (4G2.5+(2x1.5)C)C 14.5 7.5 PUR O.I. 06 MAT9851509 (4G1.5+(2x1.5)C) 12.5 10
PUR M.I. 07 MAT9060020 (4G1.5+(2x1.5)C) 13.0 7.5
Basic cable
Basic cable
6FX_002-5DN26
PVC O.I. 04 MAT97515125 (4G1.5+(2x1.5)C) 12.5 10 6FX_002-5DS06
PVC M.I. 05 MAT97515126 (4G1.5+(2x1.5)C) 13.0 7.5 PVC O.I. 04 MAT97515105 (4G1.5+(2x1.5)C) 12.5 10
PUR O.I. 06 MAT98515145 (4G1.5+(2x1.5)C) 12.5 10 PVC M.I. 05 MAT97515104 (4G1.5+(2x1.5)C) 13.0 7.5
PUR M.I. 07 MAT98515146 (4G1.5+(2x1.5)C) 13.0 7.5 PUR O.I. 06 MAT98515124 (4G1.5+(2x1.5)C) 12.5 10
PUR M.I. 07 MAT98515125 (4G1.5+(2x1.5)C) 13.0 7.5
Basic cable
Basic cable
6FX_002-5DN30
PVC O.I. 04 MAT9761566 (4G1.5+(2x1.5)C) 12.5 10 6FX_002-5DS11
PVC M.I. 05 MAT98615117 (4G1.5+(2x1.5)C) 13.0 7.5 PVC O.I. 04 MAT9751516 (4G2.5+(2x1.5)C)C 14.0 10
PUR O.I. 06 MAT9761565 (4G1.5+(2x1.5)C) 12.5 10 PVC M.I. 05 MAT9751515 (4G2.5+(2x1.5)C)C 14.5 7.5
PUR M.I. 07 MAT98615116 (4G1.5+(2x1.5)C) 13.0 7.5 PUR O.I. 06 MAT9851523 (4G2.5+(2x1.5)C)C 14.0 10
PUR M.I. 07 MAT9851522 (4G2.5+(2x1.5)C)C 14.5 7.5
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
®
®
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
