Harnessed drive cables | Siemens, SpeedTec Harnessed drive cables | Siemens, SpeedTec
Siemens Siemens
PVC/PUR/TPE EPLAN macros available online Page 582/583 PVC/PUR/TPE EPLAN macros available online Page 582/583
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor nomi- Ø R min. Cable quality Part No. Number of cores and conductor nomi- Ø R min.
nal cross section nal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Siemens Power cables, SpeedTec Siemens Power cables, SpeedTec
Basic cable, SpeedTec Basic cable, SpeedTec
6FX_002-5CG10 6FX_002-5CN01
PVC M.I. 01 MAT9761540 (4G1.5)C 10.0 7.5 PVC M.I. 01 MAT9761531 (4G1.5)C 10.0 7.5
PUR O.I. 06 MAT9861584 (4G1.5)C 9.0 10 PUR O.I. 06 MAT9861571 (4G1.5)C 9.0 10
PUR M.I. 07 MAT9861583 (4G1.5)C 11.0 7.5 PUR M.I. 07 MAT9861570 (4G1.5)C 11.0 7.5
TPE F 02 MAT9961540 (4G1.5)C 10.0 7.5 TPE F 02 MAT9961531 (4G1.5)C 10.0 7.5
6FX_002-5CG12 6FX_002-5CN11
PVC M.I. 01 MAT9761541 (4G2.5)C 11.5 7.5 PVC M.I. 01 MAT9761532 (4G2.5)C 11.5 7.5
PUR O.I. 06 MAT9861586 (4G2.5)C 10.5 10 PUR O.I. 06 MAT9861573 (4G2.5)C 10.5 10
PUR M.I. 07 MAT9861585 (4G2.5)C 12.5 7.5 PUR M.I. 07 MAT9861572 (4G2.5)C 12.5 7.5
TPE F 02 MAT9961541 (4G2.5)C 11.5 7.5 TPE F 02 MAT9961532 (4G2.5)C 11.5 7.5
6FX_002-5CG22 6FX_002-5CN21
PVC M.I. 01 MAT9761542 (4G1.5)C 10.0 7.5 PVC M.I. 01 MAT9761533 (4G1.5)C 10.0 7.5
PUR O.I. 06 MAT9861588 (4G1.5)C 9.0 10 PUR O.I. 06 MAT9861575 (4G1.5)C 9.0 10
PUR M.I. 07 MAT9861587 (4G1.5)C 11.0 7.5 PUR M.I. 07 MAT9861574 (4G1.5)C 11.0 7.5
TPE F 02 MAT9961542 (4G1.5)C 10.0 7.5 TPE F 02 MAT9961533 (4G1.5)C 10.0 7.5
6FX_002-5CG32 6FX_002-5CN31
PVC M.I. 01 MAT9761543 (4G2.5)C 11.5 7.5 PVC M.I. 01 MAT9761534 (4G2.5)C 11.5 7.5
PUR O.I. 06 MAT9861590 (4G2.5)C 10.5 10 PUR O.I. 06 MAT9861577 (4G2.5)C 10.5 10
PUR M.I. 07 MAT9861589 (4G2.5)C 12.5 7.5 PUR M.I. 07 MAT9861576 (4G2.5)C 12.5 7.5
TPE F 02 MAT9961543 (4G2.5)C 11.5 7.5 TPE F 02 MAT9961534 (4G2.5)C 11.5 7.5
6FX_002-5CG42 6FX_002-5CN41
PVC M.I. 01 MAT9761544 (4G4.0)C 13.0 7.5 PVC M.I. 01 MAT9761535 (4G4.0)C 13.0 7.5
PUR O.I. 06 MAT9861591 (4G4.0)C 12.5 10 PUR O.I. 06 MAT9861578 (4G4.0)C 12.5 10
TPE F 02 MAT9961544 (4G4.0)C 13.0 7.5 TPE F 02 MAT9961535 (4G4.0)C 13.0 7.5
6FX_002-5CG52 6FX_002-5CN51
PVC M.I. 01 MAT9761545 (4G6.0)C 16.0 7.5 PVC M.I. 01 MAT9761536 (4G6.0)C 16.0 7.5
PUR O.I. 06 MAT9861592 (4G6.0)C 14.5 10 PUR O.I. 06 MAT9861579 (4G6.0)C 14.5 10
TPE F 02 MAT9961545 (4G6.0)C 16.0 7.5 TPE F 02 MAT9961536 (4G6.0)C 16.0 7.5
6FX_002-5CG62
PVC M.I. 01 MAT9761546 (4G10)C 18.5 7.5 Basic cable, SpeedTec
PUR O.I. 06 MAT9861593 (4G10)C 170 10
TPE F 02 MAT9961546 (4G10)C 18.5 7.5 6FX_002-5CN54
PVC M.I. 01 MAT9761537 (4G6.0)C 16.0 7.5
PUR O.I. 06 MAT9861580 (4G6.0)C 14.5 10
TPE F 02 MAT9961537 (4G6.0)C 16.0 7.5
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
®
®
