Harnessed drive cables | Siemens Harnessed drive cables | Siemens
Siemens Siemens
PVC/PUR EPLAN macros available online Page 582/583 PVC/PUR EPLAN macros available online Page 582/583
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor nomi- Ø R min. Cable quality Part No. Number of cores and conductor nomi- Ø R min.
nal cross section nal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Siemens Signal cables Siemens Signal cables
Basic cable Basic cable
6FX_002-2DC10 6FX_002-5BL03
PVC 08 MAT9741504 (2x(2x0.15)+(2x0.38))C 7.5 10 PVC M.I. 18 MAT9711502 (3G0.75)C 8.0 7.5
PUR O.I. 09 MAT9841530 (2x(2x0.15)+(2x0.38))C 7.5 10 PUR M.I. 22 MAT9811501 (3G0.75)C 8.0 6.8
PUR M.I. 10 MAT9070030 (2x(2x0.20)+(2x0.38))C 7.5 7.5
Basic cable
Extension cable
6fx3002-2CT10
6FX_002-2DC34 PVC 08 MAT9741507 (4x(2x0.34)+4x0.5)C 9.5 10
PVC 08 MAT9741509 (2x(2x0.15)+(2x0.38))C 7.5 10 PUR O.I. 09 MAT9841548 (4x(2x0.34)+4x0.5)C 9.5 10
PUR O.I. 09 MAT9841551 (2x(2x0.15)+(2x0.38))C 7.5 10 PUR M.I. 10 MAT9841549 (4x(2x0.34)+4x0.5)C 10.0 7.5
PUR M.I. 10 MAT9841571 (2x(2x0.20)+(2x0.38))C 7.5 7.5 TPE H* 11 MAT9941501 (4x(2x0.34)+4x0.5)C 10.0 6.8
Basic cable Extension cable
6FX_002-2DC36 6FX8002-2CQ34
PVC 08 MAT9741528 (2x(2x0.15)+(2x0.38))C 7.5 10 PVC 08 MAT9741516 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.0 10
PUR O.I. 09 MAT98415107 (2x(2x0.15)+(2x0.38))C 7.5 10 PUR O.I. 09 MAT9841560 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.0 10
PUR M.I. 10 MAT98415108 (2x(2x0.20)+(2x0.38))C 7.5 7.5 PUR M.I. 10 MAT9841561 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 11.0 7.5
TPE H* 11 MAT9941504 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.5 6.8
Basic cable
Extension cable
6FX_002-2EQ00
PVC 08 MAT9170016 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.0 10 6FX_002-2AD04
PUR M.I. 10 MAT9841516 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 11.0 7.5 PVC 08 MAT9171001 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 9.0 10
TPE H* 11 MAT9070016 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.5 6.8 PUR M.I. 10 MAT9841520 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 10.0 7.5
TPE H* 11 MAT9071001 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 10.0 6.8
Basic cable 6FX_002-2AH04
PVC 08 MAT9171018 (4x(2x0.34)+4x0.5)C 9.5 10
6FX_002-2EQ10 PUR M.I. 10 MAT9841529 (4x(2x0.34)+4x0.5)C 10.0 7.5
PVC 08 MAT9170017 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.0 10 TPE H* 11 MAT9071018 (4x(2x0.34)+4x0.5)C 10.0 6.8
PUR M.I. 10 MAT9841517 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 11.0 7.5 6FX_002-2CA34
TPE H* 11 MAT9070017 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.5 6.8 PVC 08 MAT9171004 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.0 10
6FX_002-2EQ20 PUR M.I. 10 MAT9841523 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 11.0 7.5
PVC 08 MAT9741530 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.0 10 TPE H* 11 MAT9071004 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.5 6.8
PUR O.I. 09 MAT98415109 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.0 10 6FX_002-2CA54
PUR M.I. 10 MAT98415110 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 11.0 7.5 PVC 08 MAT9171003 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 9.0 10
TPE H* 11 MAT9941508 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.5 6.8 PUR M.I. 10 MAT9841522 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 10.0 7.5
6FX_002-2EQ31 TPE H* 11 MAT9071003 (3x(2x0.14)C+(4x0.14)+(2x0.5))C 10.0 6.8
PVC 08 MAT9741512 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.0 10
PUR O.I. 09 MAT9841554 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.0 10
PUR M.I. 10 MAT9841555 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 11.0 7.5
TPE H* 11 MAT9941502 (3x(2x0.14)C+(4x0.14)+(4x0.25)+(2x0.5))C 10.5 6.8 Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
ASEAN2023 ASEAN2023 * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
770 EPLAN download, configurators www.igus-asean.com/readycable 100 % digitally tested ... to your required length, no minimum order quantity ... 36-month chainflex guarantee 771
®
