TE/INTER- TE/INTER-
CONTEC TE/INTERCONTEC | Series 615 TE/INTERCONTEC | Series 615 CONTEC
Series 615 Series 615

Example image Example image

Signal connector [12-pole] (plastic clamping ring, EMC shielding) Signal connector [12-pole], nickel-plated (metal clamping ring, EMC shielding)
Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping
(material) crimping range range tool (material) crimping insert range range tool + insert
insert + insert [mm] [mm²] [mm]

[mm] [mm²] [mm]
MAT01730636 P type Female crimp, 12x1 0.1-0.75 4.5-6.5 C 14

P type Female crimp, 12-pole slotted
MAT01730633 12x1 0.1-0.75 4.5-6.5 C 14

12-pole slotted
P type Female crimp,
MAT01730637 12x1 0.1-0.75 6.5-8.5 C 14

P type Female crimp, 12-pole slotted
MAT01730634 12x1 0.1-0.75 6.5-8.5 C 14

12-pole slotted
P type Female crimp,
MAT01730638 12x1 0.1-0.75 8.5-10.5 C 14

P type Female crimp, 12-pole slotted
MAT01730635 12x1 0.1-0.75 8.5-10.5 C 14

12-pole slotted

Example image Example image

Signal coupling [12-pole] (plastic clamping ring, EMC shielding) Signal coupling [12-pole], nickel-plated (metal clamping ring, EMC shielding)
Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping Part No. Insulation body Contact type Dimensions Crimping Clamping Crimping
(material) crimping insert range range tool + insert (material) crimping insert range range tool + insert
[mm] [mm²] [mm] [mm] [mm²] [mm]

E type E type
MAT01730640 Male crimp 12x1 0.1-0.75 4.5-6.5 C 14 MAT01730643 Male crimp 12x1 0.1-0.75 4.5-6.5 C 14

12-pole 12-pole
E type E type
MAT01730641 Male crimp 12x1 0.1-0.75 6.5-8.5 C 14 MAT01730644 Male crimp 12x1 0.1-0.75 6.5-8.5 C 14

12-pole 12-pole
E type E type
MAT01730642 Male crimp 12x1 0.1-0.75 8.5-10.5 C 14 MAT01730645 Male crimp 12x1 0.1-0.75 8.5-10.5 C 14

12-pole 12-pole

+
Crimping tools and inserts  Page 818 Crimping tools and inserts  Page 818
