chainfix chainfi x strain relief | Clip-on solutions

CFV strain relief element - for a stepped strain relief for use
outside of the e-chain section
®
● Easy strain relief for cables, even in fully enclosed tubes and
with diff erent connectors
● For e-chains and e-tubes
®
● Subsequent installation into KMA mounting bracket or top-
hat (DIN) rail 15 (TS92.31) possible

CFV | Strain relief elements with tiewrap teeth For the following
igus series
®
Part No. For Inner height For E2/000
series hi [mm] use in ● 2600/2700
CFV.31.N15 E4.31L/R4.31L 31 Top-hat (DIN) rail 15 (TS92.31) ● 2650/2680
● 3400/3500
● 3450/3480
32 CFV.31.N15
R2.1
12 11.6
● R2.26
● R2.40
CFV.R2.26.Z R2.26 26 KMA* E4.1L
● E4.31L/R4.31L
33.8 CFV.R2.26.Z ● E4.38L/R4.38L
●
E4.48L/R4.48L
10 25.5 ● E4.64L
E4Q
CFV.R2.40.Z R2.40 40 KMA* ● E4Q.34/H4Q.34
● E4Q.44/H4Q.44
● E4Q.58/H4Q.58
49.7 CFV.R2.42.Z ● E4Q.82/H4Q.82
12 39 E4.1
● E4.32/H4.32/R4.32
CFV.42.C 2600/2700/2650/2680 35 KMA* ● E4.42/H4.42/R4.42
3400/3500/3450/3480 45 KMA* ● E4.56/H4.56/R4.56
E4Q.34/H4Q.34 32 KMA* ● E4.80/H4.80/R4.80
46.2 CFV.42.C E4.32/H4.32/R4.32 32 KMA*
KMA*
E4Q.44/H4Q.44
42
16 28 E4.42/H4.42/R4.42 42 KMA*
E4.38L/R4.38L 38 KMA*
E4.48L/R4.48L 48 KMA*
CFV.80.C R2.75 75 KMA*
E4.64L 64 KMA*
E4Q.58/H4Q.58 56 KMA*
76.2 CFV.80.C E4.56/H4.56/R4.56 56 KMA*
E4Q.82/H4Q.82 80 KMA* CFV stepped strain relief
16 28
E4.80/H4.80/R4.80 80 KMA* elements easily clipped on
*KMA = polymer metal mounting bracket from above
