chainfi x strain relief elements | Honeycomb strain relief            chainfix
                        CFU.V Honeycomb strain relief | Assembly instruction | Design


                          1                                     2

















                        Remove the top side with a hexagon wrench,   ... fi ll the CFU.V honeycomb with diff erent cables
                        openable on both sides ...             (with diameters from 2mm to 17mm)


                          3                                     4

















                        Close the top ...                      ... and screw the top side down with a hexagon
                                                               wrench


                             An assembly video is available online at
                               www.igus-asean.com/info/cfu-honeycomb-strain-relief
