Page 1426 - IGUS ECS CATALOG

chainfix chainfi x strain relief | Tiewrap plates | Optional

Option 4: chainfi x tiewrap plates for fi xed crossbars
● Can be clipped on fi xed crossbars
● For use with many harnessed cables
● If the KMA is too small for C-profi le
● Easy to assemble without any screws

Option 3 | Tiewrap plate for fi xed crossbars For the following
®
igus series
Part No. Width Number For easy chain ®
Tiewrap plates [mm] of teeth series ● E200/Z200
2050.Z 60 6 E/Z200, 2400/2500, 2600/2700 E2.1
3050.Z 50 5 3400/3500 ● E2.38
3075.Z 74 7 3400/3500 ● E2.48
C.2.522.050.ZS 48 4 E2.38, E2.48 E2/000
C.2.522.065.ZS 63 6 E2.38, E2.48 ● 2400/2500
C.2.522.075.ZS 73 7 E2.38, E2.48 ● 2600/2700
● 3400/3500

1424 More information www.igus-asean.com/tiewrap_plate
