chainfi x strain relief | Tiewrap plates | Universal chainfix

Option 1B: chainfi x tiewrap plate Series 3000
Available as an individual component
● Screwed on KMA with C-profi le
(KMA = plastic metal mounting bracket)
● Can be clipped onto some mounting brackets
● Can be used as an individual part in switchgear cabinets or
in the assembly of machines

Series 3000 | Tiewrap plate as an individual part For the following
8 6
igus series
®
A
easy chain ®
B 2
Tiewrap plate ● E26/Z26
● E300/Z300
separately
18 12 E2.1
C 12/90° 6.2 ● E2.38
44 ● E2.48
28 E2/000
● 2600/2700/2650/2680
2 35
Shown assembled ● 3400/3500/3450/3480
2 8 E4.1L
(n-1) x 10 ● E4.38L/R4.38L
● E4.48L/R4.48L
Part No. Number A B C Centre bore ● E4.64L
Tiewrap plates of teeth [n] [mm] [mm] [mm] – = no / + = yes E4Q
● E4Q.34/H4Q.34
3050.ZB 5 50 30 – –
● E4Q.44/H4Q.44
3075.ZB 7 75 55 – –
● E4Q.58/H4Q.58
3100.ZB 10 100 80 – – ● E4Q.82/H4Q.82
3115.ZB 11 115 95 – – E4.1
3125.ZB 12 125 105 – – ● E4.32/H4.32/R4.32
● E4.42/H4.42/R4.42
3150.ZB 15 150 130 – –
● E4.56/H4.56/R4.56
3175.ZB 17 175 155 – –
● E4.80/H4.80/R4.80
3200.ZB 20 200 180 90 + ● E4.112/R4.112
3225.ZB 22 225 205 102.5 + ● E4.162
3250.ZB 25 250 230 115 + ● 800
● 840
E4/light
Cable tiewraps as individual parts ● 14040/14140/18840
● 14240/14340
Part No. cable tiewraps Width x length ≤ ø Tensile strength ● 14550/14650/19050
100-piece bag [mm] [mm] [N] ● 15050/15150/19850
● 15250/15350
CFB.001 4.8 x 150 36 222 N
● 1640/1608
E6.1
● E61.52
● E61.62
● E61.80
E6
● E6.52/R6.52
● E6.62
● E6.80L
● E6.80
3D-CAD, confi gurators, service life calculation and more www.igus-asean.com/chainfi x 1421
