P. 655

E4.42
                        E4.1 | e-tubes R4.42 | Accessories                                   H4.42
                                                                                             R4.42
                        KMA mounting brackets | Attachment from any side | Pivoting | Locking


                           Fixed end                   Moving end  Front view
                          R4.420/421 ...  .1        R4.420/421 ...  * .2  of KMA          Pivoting angle
                                   *
                                 82                      82         64                    depends
                                                                                          on radius
                                                                                      30°

                                  6.5
                                                                                          Pivoting angle
                          Bi + 32  Bi + 16     Bi               Bi + 16  Bi               depends
                                                                                          on radius





                                                                              Moving end
                           15     22.5                 22.5    15   22
                                                                              Fixed end
                        KMA pivoting  | Recommended for unsupported and gliding applications
                        KMA locking  | Recommended for vertical hanging and standing applications

                        Width   Part No. Full set  Part No. Full set  Bi  Width   Part No. Full set  Part No. Full set  Bi
                        index  KMA pivoting  KMA locking  [mm]  index  KMA pivoting  KMA locking  [mm]
                        05.  ▼  R4.420.05 . .12.C  R4.421.05 . .12.C  50  12.  ▼  R4.420.12. . .12.C   R4.421.12 . .12.C   125
                                     *
                                                  *
                                                                                       *
                                                                          *
                        06.  ▼  R4.420.06 . .12.C  R4.421.06 . .12.C  68  15.  ▼  R4.420.15 . .12.C   R4.421.15 . .12.C   150
                                                                                       *
                                                  *
                                                                          *
                                     *
                        07.  ▼  R4.420.07 . .12.C  R4.421.07 . .12.C  75  17.  ▼  R4.420.17 . .12.C   R4.421.17 . .12.C   168
                                                                                       *
                                                  *
                                                                          *
                                     *
                        087.  ▼  R4.420.087. .12.C  R4.421.087. .12.C  087  20.  ▼  R4.420.20 . .12.C  R4.421.20 . .12.C  200
                                                                                       *
                                                  *
                                                                          *
                                     *
                        10.  ▼  R4.420.10 . .12.C  R4.421.10 . .12.C  100  25.  ▼  R4.420.25 . .12.C  R4.421.25 . .12.C  250
                                                                                       *
                                                                          *
                                                  *
                                     *
                        11.  ▼  R4.420.11 . .12.C  R4.421.11 . .12.C  108  30.  ▼  R4.420.30 . .12.C  R4.421.30 . .12.C  300
                                                  *
                                                                          *
                                     *
                                                                                       *
                        (KMA = polymer metal mounting br
                        (KMA = polymer metal mounting bracket)  For the C-profi le option please add index .Cacket)  For the C-profi le option please add index .C
                         Note  : The e-chains ®  may end with either an inner or an outer side link. An outer   2  1  2  1
                         side link should always be the fi rst e-chain ®  link at the moving end. Please specify   3  = 1  3  = 2
                         the index   (for odd) or   (for even) depending on an even or odd number of links   4  4
                                                                             5           5
                         required.                                            6  7  8  9  6  7  8
                                                                           E4.420.30.2.12.C.A2 Order example
                                                                                           to indicate option
                                                                                       with brackets pre-fi tted
                            .A         .A1      .A2      .A3      .A4                  C-profi le option
                                                                                       Full set
                         Possible orientations for KMA mounting brackets. For mounting brackets pre-fi tted   Even numbers of links
                         without C-profi le, please attach index .A . For types pre-fi tted with C-profi le
                         please attach index .A1, .A2, .A3 or .A4.                     width index
                                                                                       Series
                             Strain relief e.g. clamps, tiewrap plates, nuggets and clips are available from stock. The complete
                             chainfi x range with ordering options   From page 1392
                               3D CAD, confi gurators, service life calculation and more   www.igus-asean.com/E4.1  653
