Timing Belts H

Timing Pulleys Nominal Width 150 (1.5inch, 38.1mm),
Number of Teeth 63

P.241 %
Saving Up to 80
vs Standard Type Shipping
Idlers from

40.82 MYR 9 days
P.263
Timing Belts For price with different specification, please check our website

P.289
Pitch: 12.7mm Back side
Closed Belts Rr Ra h H Toothed Face

P.317 șș Lr
.Material: Tooth Surface Protection Layer
Open End Belts Tooth Rubber : Chloroprene Rubber
: Nylon Cloth
: Glass Fiber
Core Wire
P.323 How to create a Types Nominal Pitch 2θ Lr h H Rr Ra Unit weight g/m
(mm)
Width
(Width: 10mm)
model
Clamp Plates for Open End Belts 1.Search this keyword (19.1mm)
075
MISUMI WEB
100
timing belt h
P.327 2.Select Economy series H (25.4mm) 12.7 40° 6.12 2.29 4.30 1 1 40
5 Brand 150
MISUMI (38.1mm)
Economy series
200
Timing Pulleys / Idlers / Timing Belts & The meaning of the belt number of toothed timing belt varies with type, and the belt circumference length of L (inch size) is
(50.8mm)
the belt number. Please be careful.
&Belt operating temperature range: -30 to 90°C.
&The model engraved on the back of the product is the factory-managed model, which may be different from the actual product.
& For the transmission capacity, calculation and design method of economy series timing belt, please refer to the national
standard (GB) design manual.
&Weight is a theoretical value for reference only, which may be different from the actual product.
Number Belt Number Belt
How to create a Belt Nominal of Circumference How to create a Belt Nominal of Circumference
model Number Width model Number Width
Teeth Length (mm) Teeth Length (mm)
120H 24 304.8 290H 58 736.6
185H 37 469.9 300H 60 762.0
200H 40 508.0 310H 62 787.4
210H 42 533.4 315H 63 800.1
220H 075 44 558.8 320H 075 64 812.8
225H (19.1mm) 45 571.5 325H (19.1mm) 65 825.5
MISUMI WEB MISUMI WEB
1.Search this keyword 230H 100 46 584.2 1.Search this keyword 330H 100 66 838.2
timing belt h 240H (25.4mm) 48 609.6 timing belt h 335H (25.4mm) 67 850.9
2.Select Economy series 245H 150 49 622.3 2.Select Economy series 340H 150 68 863.6
Brand Brand
MISUMI 250H (38.1mm) 50 635.0 MISUMI 345H (38.1mm) 69 876.3
Economy series Economy series
255H 200 51 647.7 350H 200 70 889.0
260H (50.8mm) 52 660.4 360H (50.8mm) 72 914.4
270H 54 685.8 365H 73 927.1
275H 55 698.5 370H 74 939.8
280H 56 711.2 375H 75 952.5
285H 57 723.9 380H 76 965.2
