Page 311 - MiSUMi FA Mechanical Components Economy Series

Number Belt Number Belt Pulleys Timing
How to create a Belt Nominal of Circumference How to create a Belt Nominal of Circumference
model Number Width model Number Width
Teeth Length (mm) Teeth Length (mm)
158XL 79 401.32 306XL 153 777.24 P.241
160XL 80 406.40 310XL 155 787.40
162XL 81 411.48 314XL 157 797.56
164XL 82 416.56 316XL 158 802.64 Idlers
166XL 83 421.64 320XL 160 812.80
168XL 84 426.72 322XL 161 817.88
170XL 85 431.80 326XL 163 828.04 P.263
172XL 86 436.88 330XL 165 838.20
174XL 87 441.96 332XL 166 843.28
176XL 88 447.04 336XL 168 853.44
178XL 89 452.12 338XL 169 858.52 Timing Belts
180XL 90 457.20 340XL 170 863.60
182XL 91 462.28 344XL 172 873.76
184XL 92 467.36 348XL 174 883.92 P.289
186XL 93 472.44 350XL 175 889.00
188XL 94 477.52 352XL 176 894.08
190XL 95 482.60 356XL 178 904.24
192XL 96 487.68 360XL 180 914.40 Closed Belts
194XL 97 492.76 362XL 181 919.48
196XL 98 497.84 364XL 182 924.56
198XL 99 502.92 370XL 185 939.80 P.317
200XL 100 508.00 372XL 186 944.88
202XL 101 513.08 376XL 188 955.04
204XL 102 518.16 380XL 190 965.20
206XL 103 523.24 382XL 191 970.28 Belts Open End
208XL 104 528.32 384XL 192 975.36
210XL 105 533.40 388XL 025 194 985.52
212XL 025 106 538.48 390XL (6.4mm) 195 990.60 P.323
MISUMI WEB 214XL (6.4mm) 107 543.56 392XL 196 995.68
1.Search this keyword 216XL 031 108 548.64 MISUMI WEB 396XL 031 198 1005.84
timing belt xl 218XL (7.9mm) 109 553.72 1.Search this keyword 400XL (7.9mm) 200 1016.00 Open End Belts Clamp Plates for
2.Select Economy series 220XL 037 110 558.80 timing belt xl 412XL 037 206 1046.48
Brand 222XL 111 563.88 414XL (9.5mm) 207 1051.56
MISUMI 224XL (9.5mm) 112 568.96 2.Select Economy series 420XL 210 1066.80
Economy series Brand 050 P.327
226XL 050 113 574.04 MISUMI 424XL 212 1076.96
228XL (12.7mm) 114 579.12 Economy series 430XL (12.7mm) 215 1092.20 5
230XL 115 584.20 432XL 216 1097.28
234XL 117 594.36 434XL 217 1102.36
236XL 118 599.44 450XL 225 1143.00
240XL 120 609.60 460XL 230 1168.40
244XL 122 619.76 470XL 235 1193.80 Idlers / Timing Belts Timing Pulleys /
246XL 123 624.84 480XL 240 1219.20
248XL 124 629.92 490XL 245 1244.60
250XL 125 635.00 492XL 246 1249.68
252XL 126 640.08 506XL 253 1285.24
254XL 127 645.16 510XL 255 1295.40
256XL 128 650.24 522XL 261 1325.88
258XL 129 655.32 530XL 265 1346.20
260XL 130 660.40 560XL 280 1422.40
264XL 132 670.56 564XL 282 1432.56
266XL 133 675.64 576XL 288 1463.04
268XL 134 680.72 580XL 290 1473.20
270XL 135 685.80 592XL 296 1503.68
274XL 137 695.96 612XL 306 1554.48
276XL 138 701.04 616XL 308 1564.64
278XL 139 706.12 630XL 315 1600.20
280XL 140 711.20 646XL 323 1640.84
282XL 141 716.28 670XL 335 1701.80
286XL 143 726.44 700XL 350 1778.00
290XL 145 736.60 828XL 414 2103.12
296XL 148 751.84 860XL 430 2184.40
300XL 150 762.00 964XL 482 2448.56
304XL 152 772.16 &Please refer to the official website for more specifications
&Belt circumference length is a reference value.
How to create Search on MISUMI official website Configure Clear All
a model Step Step Select Brand Brand
1 timing belt xl 2 MISUMI MISUMI
Economy Series
Input the keyword and search on the website
Economy series
