Page 307 - MiSUMi FA Mechanical Components Economy Series

Belt Belt Pulleys Timing
How to create a Belt Nominal Number How to create a Belt Nominal Number
model Number Width of Teeth Circumference model Number Width of Teeth Circumference
Length (mm) Length (mm)
776H8M 97 776 1408H8M 176 1408 P.241
784H8M 98 784 1416H8M 177 1416
792H8M 99 792 1424H8M 178 1424
800H8M 100 800 1432H8M 179 1432 Idlers
808H8M 101 808 1440H8M 180 1440
816H8M 102 816 1448H8M 181 1448
824H8M 103 824 1456H8M 182 1456
832H8M 104 832 1464H8M 183 1464 P.263
840H8M 105 840 1480H8M 185 1480
848H8M 106 848 1512H8M 189 1512
856H8M 107 856 1520H8M 190 1520 Timing Belts
888H8M 111 888 1528H8M 191 1528
896H8M 112 896 1536H8M 192 1536
912H8M 114 912 1552H8M 194 1552
920H8M 115 920 1560H8M 195 1560 P.289
928H8M 116 928 1576H8M 197 1576
936H8M 117 936 1584H8M 198 1584
944H8M 118 944 1600H8M 200 1600 Closed Belts
952H8M 119 952 1648H8M 206 1648
960H8M 120 960 1656H8M 207 1656
968H8M 121 968 1680H8M 210 1680
976H8M 122 976 1696H8M 212 1696 P.317
984H8M 123 984 1704H8M 213 1704
992H8M 124 992 1720H8M 215 1720
1000H8M 125 1000 1728H8M 216 1728 Belts Open End
1032H8M 129 1032 1760H8M 200 220 1760
1040H8M 200 130 1040 1768H8M (20mm) 221 1768
1048H8M (20mm) 131 1048 1776H8M 222 1776
1056H8M 250 132 1056 1784H8M 250 223 1784 P.323
1064H8M 133 1064 1792H8M (25mm) 224 1792
MISUMI WEB 1072H8M (25mm) 134 1072 MISUMI WEB 1800H8M 225 1800
1.Search this keyword 1080H8M 300 135 1080 1.Search this keyword 1824H8M 300 228 1824
timing belt htd 1088H8M (30mm) 136 1088 timing belt htd 1840H8M (30mm) 230 1840 Open End Belts Clamp Plates for
2.Select Economy series 1096H8M 400 137 1096 2.Select Economy series 1848H8M 400 231 1848
Brand 1104H8M 138 1104 Brand 1856H8M (40mm) 232 1856
MISUMI (40mm) MISUMI P.327
Economy series 1112H8M 139 1112 Economy series 1880H8M 500 235 1880
1120H8M 500 140 1120 1896H8M (50mm) 237 1896 5
1128H8M (50mm) 141 1128 1912H8M 239 1912
1136H8M 850 142 1136 1936H8M 850 242 1936
1144H8M (85mm) 143 1144 1952H8M (85mm) 244 1952
1152H8M 144 1152 2000H8M 250 2000
1160H8M 145 1160 2016H8M 252 2016
1168H8M 146 1168 2048H8M 256 2048 Idlers / Timing Belts Timing Pulleys /
1176H8M 147 1176 2080H8M 260 2080
1184H8M 148 1184 2104H8M 263 2104
1192H8M 149 1192 2160H8M 270 2160
1200H8M 150 1200 2184H8M 273 2184
1208H8M 151 1208 2208H8M 276 2208
1216H8M 152 1216 2240H8M 280 2240
1224H8M 153 1224 2400H8M 300 2400
1232H8M 154 1232 2504H8M 313 2504
1272H8M 159 1272 2560H8M 320 2560
1280H8M 160 1280 2656H8M 332 2656
1288H8M 161 1288 2736H8M 342 2736
1296H8M 162 1296 2840H8M 355 2840
1304H8M 163 1304 3048H8M 381 3048
1312H8M 164 1312 3120H8M 390 3120
1320H8M 165 1320 3200H8M 400 3200
1328H8M 166 1328 3280H8M 410 3280
1336H8M 167 1336 3400H8M 425 3400
1344H8M 168 1344 3424H8M 428 3424
1360H8M 170 1360 3824H8M 478 3824
1368H8M 171 1368 4224H8M 528 4224
1384H8M 173 1384 4520H8M 565 4520
1392H8M 174 1392 5120H8M 640 5120
1400H8M 175 1400 &Please refer to the official website for more specifications
