Page 308 - MiSUMi FA Mechanical Components Economy Series

Timing Belts MXL

Timing Pulleys Nominal Width 025 (0.25inch, 6.4mm),
Number of Teeth 144

P.241 %
Saving Up to 69
vs Standard Type Shipping
Idlers from

5.86 MYR 1 day
P.263
Timing Belts For price with different specification, please check our website

P.289
Pitch: 2.032mm Back side
Closed Belts Rr Ra h H Toothed Face

P.317 șș Lr
.Material: Tooth Fabric : Nylon Cloth
Open End Belts Tooth Rubber : Chloroprene Rubber
: Glass Fiber
Core Wire
How to create a Nominal Pitch Unit weight g/m
P.323 model Types Width (mm) 2θ Lr h H Rr Ra (Width: 10mm)
Clamp Plates for Open End Belts 1.Search this keyword (4.8mm)
019
MISUMI WEB
025
timing belt mxl
P.327 2.Select Economy series MXL (6.4mm) 2.032 40° 1.14 0.51 1.22 0.13 0.13 11
037
5 Brand MISUMI (9.5mm)
Economy series (12.7mm)
050
Timing Pulleys / Idlers / Timing Belts & The meaning of the belt number of toothed timing belt varies with type, and the number of belt teeth for MXL is the belt
number. Please be careful.
&Belt operating temperature range: -30 to 90°C.
& The model engraved on the back of the product is the factory-managed model, which may be different from the actual product.
& For the transmission capacity, calculation and design method of economy series timing belt, please refer to the national
standard (GB) design manual.
&Weight is a theoretical value for reference only, which may be different from the actual product.
Number Belt Number Belt
How to create a Belt Nominal How to create a Belt Nominal
model Number Width of Circumference model Number Width of Circumference
Teeth Length (mm) Teeth Length (mm)
45MXL 45 91.44 71MXL 71 144.27
48MXL 48 97.54 72MXL 72 146.30
50MXL 50 101.60 73MXL 73 148.34
52MXL 52 105.66 75MXL 75 152.40
53MXL 53 107.70 76MXL 76 154.43
54MXL 54 109.73 77MXL 77 156.46
55MXL 019 55 111.76 78MXL 019 78 158.50
56MXL (4.8mm) 56 113.79 79MXL (4.8mm) 79 160.53
MISUMI WEB MISUMI WEB
1.Search this keyword 57MXL 025 57 115.82 1.Search this keyword 80MXL 025 80 162.56
timing belt mxl 58MXL (6.4mm) 58 117.86 timing belt mxl 82MXL (6.4mm) 82 166.62
2.Select Economy series 59MXL 59 119.89 2.Select Economy series 83MXL 83 168.66
Brand 60MXL 037 60 121.92 Brand 84MXL 037 84 170.69
MISUMI 61MXL (9.5mm) 61 123.95 MISUMI 85MXL (9.5mm) 85 172.72
Economy series Economy series
62MXL 050 62 125.98 86MXL 050 86 174.75
63MXL (12.7mm) 63 128.02 87MXL (12.7mm) 87 176.78
65MXL 65 132.08 88MXL 88 178.82
66MXL 66 134.11 89MXL 89 180.85
67MXL 67 136.14 90MXL 90 182.88
68MXL 68 138.18 91MXL 91 184.91
69MXL 69 140.21 92MXL 92 186.94
70MXL 70 142.24 93MXL 93 188.98
