Page 623 - MiSUMi FA Mechanical Components Economy Series
P. 623

13
           One-Touch Strut Clamps

                                                      Equal Dia. Type, Hole Dia. D 8mm,
                                                      Surface Treatment Clear Anodized               / Angle Plates  Posts / Strut Clamps

                                                        Saving Up to        80  %
                                                       vs Standard Type
                                                                                       Shipping
                                                                                          from        Posts
                                                             11.70 MYR                  1 day
                                                                                                    P.613
                                                      For price with different specification, please check our website
                     Equal Dia. Perpendicular Type        Unequal Dia. Perpendicular Type             Strut Clamps
                                A                                   A
                           E          E                        E         G
                     2-M                                  2-M                                       P.619
                                           B                                  B                       Angle Plates
                                          2-d                               2-d
                         D                                    D
                                          2-d1 Counterbored Depth f         2-d1 Counterbored Depth f
                                       D                                  D1                        P.621

                                           C                                  C


           &  Dimension where not marked, the tolerance of П20 or less (including 20) is ±0.3.  .Material:  Aluminum Alloy
             The tolerance of П25 or more is ±0.5.                     4Surface Treatment:  Black Anodized
           &Since the slit part is machined after the mounting hole D is machined with a   Clear Anodized
             tolerance of 0 to +0.05, the hole tolerance will change.  "Accessories: Hexagon Socket Head Bolt
           2 Equal Dia. Perpendicular Type
                                                                                      Supplied Bolt
             How to create a    Hole Dia.  A  B    C      E     d            f   (Coarse Thread · Stainless Steel)
                 model        D                                       d 1
                                                                                         M
                              8       41    15     15    14
                              10      45                 15     8     4.5    4.2        M4
              MISUMI WEB                    16     16
             1.Search this keyword  12  49               16
             strut clamp      15            20     20           9     5.5    5.2        M5
             2.Select  Economy series  16  57  22  22    18
             Brand
               MISUMI         20      69    25     25    22     11    6.5    6.2        M6
                 Economy series
                              25      86    35     35    26
                              30      95    40     40    29     14    8.5    8.2        M8
           2 Unequal Dia. Perpendicular Type
                                                                                      Supplied Bolt
             How to create a    Hole    Hole   A  B   C    E   G    d         f  (Coarse Thread · Stainless Steel)
                 model      Dia. D  Dia. D 1                             d 1
                                                                                         M
                              10      8     45            15   15   8    4.5  4.2       M4
              MISUMI WEB      12            49   20   20  16   16
             1.Search this keyword  15  10  57            18   18   9    5.5  5.2       M5
             strut clamp
             2.Select  Economy series  20  15  69  25     22   22   11   6.5  6.2       M6
             Brand                    16              25
               MISUMI
                 Economy series  25   15    86   35       26   26
                              30      20    95   40   30  29   29   14   8.5  8.2       M8
             How to create                                                          Configure  Clear All
               a model  Step  Search on MISUMI official website  Step   Select  Brand  Brand
                       1      strut clamp                       2        MISUMI       MISUMI
                                                                      Economy Series
                             Input the keyword and search on the website
                                                                                       Economy series
