13 Hexagonal Posts Both Ends Tapped
Posts / Strut Clamps / Angle Plates Width across fl ats B 10mm, Length L 30mm

72
%
Saving Up to
vs Standard Type
Shipping
from
Posts 2.73 MYR 1 day

P.613
Strut Clamps M For price with different specification, please check our website

M
P.619
Angle Plates B (C)

P.621 M×2 L±0.2 M×2
.Material: General Structural Steel or
SUM Material
4Surface Treatment: Electroplated Nickel
Plating or Electroless
Nickel Plating
How to create a Width Length L M (C)
model across flats B (Fixed Size Selection) (Coarse Thread)
6 15 20 30 40 3 6.9
MISUMI WEB 7 20 30 40 60 80 4 8.1
1.Search this keyword
hex post 8 30 40 60 80 5 9.2
2.Select Economy series
Brand 10 30 40 60 80 100 11.5
MISUMI 6
Economy series 12 30 40 60 80 100 150 200 13.9
14 40 60 80 100 150 200 8 16.2
&L≤M×4 female thread is the through hole.
&When L≤M×6, the bottom hole of the female thread may be penetrated.
&L≥M×2+N×2
How to create Configure Clear All
a model Step Search on MISUMI official website Step Select Brand Brand
1 hex post 2 MISUMI MISUMI
Economy Series
Input the keyword and search on the website
Economy series
Intended Use Support and Fixation

Usage
Method
Diagram

Hexagonal Posts

Feature · It can bear large load in vertical direction
