Page 1056 - IGUS Bearing

®
xiros ® xiros radial deep groove ball bearings | Product range xiros ®
Races made from xirodur F180 - antistatic
®

Order key

● Static dissipation Type Material
● Suitable for food contact according to the FDA/EU d1
regulations (combined with PE cage)
● Specific volume resistance <10 Ωcm
12
PA cage, PE cage, ● Operating temperature: from -40°C up to +80°C
stainless steel balls stainless steel balls d2 b1 according to DIN 625-1

Ball bearing Dimensions Race material Cage material Ball material

Do you need an electrically conductive
material for your application?
xirodur F182 is even more conductive Options:
®
(without FDA/food approval). Cage material
Please contact us!
10 : PA
50 : PE
Ball material
ES : Stainless steel

Technical data Dimensions [mm]
Installation Radial load capacity Limit speed Weight Inner Ø OuterØ Width Cage/ball material Part No.
size stat. dyn. PA/ES PE/ES combination
[N] [N] [rpm] [g] [g] d1 d2 b1 PA/ES PE/ES
623 10 25 4,500 0.39 0.39 3 10 4 BB-623-F180- -ES
624 20 33 4,000 0.83 0.82 4 13 5 BB-624-F180- -ES
625 40 40 3,700 1.54 1.50 5 16 5 BB-625-F180- -ES
626 41 43 3,200 2.50 2.36 6 19 6 BB-626-F180- -ES
608 80 94 2,200 3.79 3.67 8 22 7 BB-608-F180- -ES
6000 110 130 2,200 5.86 5.76 10 26 8 BB-6000-F180- -ES
6001 138 147 2,000 6.72 6.62 12 28 8 BB-6001-F180- -ES
6002 140 150 1,800 8.59 8.50 15 32 9 BB-6002-F180- -ES
6003 160 220 1,600 10.53 10.39 17 35 10 BB-6003-F180- -ES
6004 250 320 1,400 19.24 19.18 20 42 12 BB-6004-F180- -ES
6005 280 360 1,200 22.43 22.04 25 47 12 BB-6005-F180- -ES

Order example: Available
BB-623-F180-10-ES = Radial deep groove ball bearing with race material xirodur F180, PA cage and stainless from stock
®
steel balls ASEAN 09/2023 ASEAN 09/2023
1054 Online tools and more information u www.igus-asean.com/xiros 3D CAD files, prices and delivery time online u www.igus-asean.com/xiros 1055
