Page 1118 - IGUS Bearing
P. 1118
Inch Inch
®
®
iglidur Imperial product range | iglidur | Sleeve bearings Imperial product range | iglidur | Sleeve bearings iglidur
®
®
form S form S
d1 d2 b1 d1 3) Housing hole Shaft size Part No. d1 d2 b1 d1 3) Housing hole Shaft size Part No.
max. min. max. min. max. min. max. min. max. min. max. min.
1 1/4 1 1/2 3/4 1.2600 1.2531 1.5005 1.4995 1.2500 1.2490 MSI-2024-12 1/2 19/32 1 .5030 .5003 .5941 .5934 .4990 .4980 PSI-0809-16
1 1/4 1 1/2 1 1.2600 1.2531 1.5005 1.4995 1.2500 1.2490 MSI-2024-16 9/16 21/32 1/2 .5655 .5627 .6566 .6559 .5615 .5605 PSI-0910-08
1 1/4 1 1/2 1 3/8 1.2600 1.2531 1.5005 1.4995 1.2500 1.2490 MSI-2024-22 9/16 21/32 5/8 .5655 .5627 .6566 .6559 .5615 .5605 PSI-0910-10
1 1/4 1 1/2 1 1/2 1.2600 1.2531 1.5005 1.4995 1.2500 1.2490 MSI-2024-24 9/16 21/32 3/4 .5655 .5627 .6566 .6559 .5615 .5605 PSI-0910-12
1 1/4 1 1/2 2 1/2 1.2600 1.2531 1.5005 1.4995 1.2500 1.2490 MSI-2024-40 5/8 23/32 1/2 .6280 .6253 .7192 .7184 .6240 .6230 PSI-1011-08
1 3/8 1 5/8 1 1.3850 1.3182 1.6255 1.6245 1.3750 1.3740 MSI-2226-16 5/8 23/32 3/4 .6280 .6253 .7192 .7184 .6240 .6230 PSI-1011-12
1 1/2 1 3/4 3/4 1.5100 1.5032 1.7505 1.7495 1.5000 1.4990 MSI-2428-12 5/8 23/32 1 .6280 .6253 .7192 .7184 .6240 .6230 PSI-1011-16
1 1/2 1 3/4 1 1.5100 1.5032 1.7505 1.7495 1.5000 1.4990 MSI-2428-16 3/4 7/8 1/2 .7541 .7505 .8755 .8747 .7491 .7479 PSI-1214-08
1 1/2 1 3/4 1 1/2 1.5100 1.5032 1.7505 1.7495 1.5000 1.4990 MSI-2428-24 3/4 7/8 3/4 .7541 .7505 .8755 .8747 .7491 .7479 PSI-1214-12
1 1/2 1 3/4 2 /2 1.5100 1.5032 1.7505 1.7495 1.5000 1.4990 MSI-2428-40 3/4 7/8 1 .7541 .7505 .8755 .8747 .7491 .7479 PSI-1214-16
1 5/8 1 7/8 1 1.6350 1.6282 1.8755 1.8745 1.6250 1.6240 MSI-2630-16 7/8 1 1/2 .8791 .8757 1.0005 .9997 .8741 .8729 PSI-1416-08
1 3/4 2 1/2 1.7560 1.7532 2.0005 1.9995 1.7500 1.7490 MSI-2832-08 7/8 1 3/4 .8791 .8757 1.0005 .9997 .8741 .8729 PSI-1416-12
1 3/4 2 3/4 1.7560 1.7532 2.0005 1.9995 1.7500 1.7490 MSI-2832-12 7/8 1 1 .8791 .8757 1.0005 .9997 .8741 .8729 PSI-1416-16
1 3/4 2 1 1.7560 1.7532 2.0005 1.9995 1.7500 1.7490 MSI-2832-16 1 1 1/8 1/2 1.0041 1.0007 1.1255 1.1247 .9991 .9979 PSI-1618-08
1 3/4 2 1 1/2 1.7560 1.7532 2.0005 1.9995 1.7500 1.7490 MSI-2832-24 1 1 1/8 3/4 1.0041 1.0007 1.1255 1.1247 .9991 .9979 PSI-1618-12
1 3/4 2 2 1/2 1.7560 1.7532 2.0005 1.9995 1.7500 1.7490 MSI-2832-40 1 1 1/8 1 1.0041 1.0007 1.1255 1.1247 .9991 .9979 PSI-1618-16
2 2 1/4 1 2.0100 2.0032 2.2505 2.2495 2.0000 1.9990 MSI-3236-16 1 1/8 1 9/32 3/4 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 PSI-1820-12
2 2 1/4 1 1/2 2.0100 2.0032 2.2505 2.2495 2.0000 1.9990 MSI-3236-24 1 1/8 1 9/32 1 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 PSI-1820-16
2 2 1/4 2 2.0100 2.0032 2.2505 2.2495 2.0000 1.9990 MSI-3236-32 1 1/8 1 9/32 1 1/4 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 PSI-1820-20
2 2 1/4 2 1/2 2.0100 2.0032 2.2505 2.2495 2.0000 1.9990 MSI-3236-40 1 1/4 1 13/32 3/4 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 PSI-2022-12
3 3 1/4 1 3.0114 3.0039 3.2505 3.2495 3.0000 2.9990 MSI-4852-16 1 1/4 1 13/32 1 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 PSI-2022-16
1 1/4 1 13/32 1 1/4 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 PSI-2022-20
iglidur P Chapter Page 135 1 1/2 1 21/32 1 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 PSI-2426-16
®
1 1/2 1 21/32 1 1/2 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 PSI-2426-24
d1 d2 b1 d1 3) Housing hole Shaft size Part No. 1 5/8 1 25/32 1 1.6297 1.6258 1.7818 1.7808 1.6238 1.6222 PSI-2629-16
max. min. max. min. max. min. 1 5/8 1 25/32 1 1/2 1.6297 1.6258 1.7818 1.7808 1.6238 1.6222 PSI-2629-24
1/8 3/16 3/16 .1269 .1251 .1878 .1873 .1243 .1236 PSI-0203-03 1 3/4 1 15/16 1 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 PSI-2831-16
3/16 1/4 1/4 .1892 .1873 .2503 .2497 .1865 .1858 PSI-0304-04 1 3/4 1 15/16 2 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 PSI-2831-32
3/16 1/4 3/8 .1892 .1873 .2503 .2497 .1865 .1858 PSI-0304-06 1 7/8 2 1/16 1 1.8796 1.8757 2.0633 2.0621 1.8737 1.8721 PSI-3033-16
1/4 5/16 3/8 .2521 .2498 .3128 .3122 .2490 .2481 PSI-0405-06 1 7/8 2 1/16 2 1.8796 1.8757 2.0633 2.0621 1.8737 1.8721 PSI-3033-32
1/4 5/16 1/2 .2521 .2498 .3128 .3122 .2490 .2481 PSI-0405-08 2 2 3/16 1 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 PSI-3235-16
5/16 3/8 1/4 .3148 .3125 .3753 .3747 .3115 .3106 PSI-0506-04 2 2 3/16 2 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 PSI-3235-32
5/16 3/8 3/8 .3148 .3125 .3753 .3747 .3115 .3106 PSI-0506-06
5/16 3/8 1/2 .3148 .3125 .3753 .3747 .3115 .3106 PSI-0506-08 iglidur P210 Chapter Page 121
®
3/8 15/32 1/4 .3773 .3750 .4691 .4684 .3740 .3731 PSI-0607-04
3/8 15/32 3/8 .3773 .3750 .4691 .4684 .3740 .3731 PSI-0607-06 d1 d2 b1 d1 3) Housing hole Shaft size Part No.
3/8 15/32 1/2 .3773 .3750 .4691 .4684 .3740 .3731 PSI-0607-08 max. min. max. min. max. min.
3/8 15/32 5/8 .3773 .3750 .4691 .4684 .3740 .3731 PSI-0607-10 1/8 3/16 3/16 .1269 .1251 .1878 .1873 .1243 .1236 P210SI-0203-03
3/8 15/32 3/4 .3773 .3750 .4691 .4684 .3740 .3731 PSI-0607-12 3/16 1/4 1/4 .1892 .1873 .2503 .2497 .1865 .1858 P210SI-0304-04
7/16 17/32 1/2 .4406 .4379 .5316 .5309 .4365 .4355 PSI-0708-08 3/16 1/4 3/8 .1892 .1873 .2503 .2497 .1865 .1858 P210SI-0304-06
7/16 17/32 3/4 .4406 .4379 .5316 .5309 .4365 .4355 PSI-0708-12 1/4 5/16 3/8 .2521 .2498 .3128 .3122 .2490 .2481 P210SI-0405-06
1/2 19/32 1/4 .5030 .5003 .5941 .5934 .4990 .4980 PSI-0809-04 1/4 5/16 1/2 .2521 .2498 .3128 .3122 .2490 .2481 P210SI-0405-08
1/2 19/32 3/8 .5030 .5003 .5941 .5934 .4990 .4980 PSI-0809-06 5/16 3/8 1/4 .3148 .3125 .3753 .3747 .3115 .3106 P210SI-0506-04
1/2 19/32 1/2 .5030 .5003 .5941 .5934 .4990 .4980 PSI-0809-08 5/16 3/8 3/8 .3148 .3125 .3753 .3747 .3115 .3106 P210SI-0506-06
1/2 19/32 5/8 .5030 .5003 .5941 .5934 .4990 .4980 PSI-0809-10 5/16 3/8 1/2 .3148 .3125 .3753 .3747 .3115 .3106 P210SI-0506-08
1/2 19/32 3/4 .5030 .5003 .5941 .5934 .4990 .4980 PSI-0809-12 3/8 15/32 1/4 .3773 .3750 .4691 .4684 .3740 .3731 P210SI-0607-04
3) After press-fit. Testing methods u Page 61 ASEAN 09/2023 ASEAN 09/2023 3) After press-fit. Testing methods u Page 61
1116 Service life calculation, configuration and more u www.igus-asean.com 3D CAD files, prices and delivery time online u www.igus-asean.com 1117
