iglidur Imperial product range | iglidur | Sleeve bearings Imperial product range | iglidur | Sleeve bearings iglidur
®
®
form S form S
d1 d2 b1 d1 3) Housing hole Shaft size Part No. d1 d2 b1 d1 3) Housing hole Shaft size Part No.
max. min. max. min. max. min. max. min. max. min. max. min.
7/8 1 1/2 0.8791 0.8757 1.0005 0.9997 0.8741 0.8729 J3SI-1416-08 1/2 19/32 3/4 .5024 .4996 .5941 .5934 .4990 .4980 J350SI-0809-12
7/8 1 3/4 0.8791 0.8757 1.0005 0.9997 0.8741 0.8729 J3SI-1416-12 1/2 19/32 1 .5024 .4996 .5941 .5934 .4990 .4980 J350SI-0809-16
7/8 1 1 0.8791 0.8757 1.0005 0.9997 0.8741 0.8729 J3SI-1416-16 9/16 21/32 1/2 .5649 .5620 .6566 .6559 .5615 .5605 J350SI-0910-08
1 1 1/8 1/2 1.0041 1.0007 1.1255 1.1247 0.9991 0.9979 J3SI-1618-08 9/16 21/32 5/8 .5649 .5620 .6566 .6559 .5615 .5605 J350SI-0910-10
1 1 1/8 3/4 1.0041 1.0007 1.1255 1.1247 0.9991 0.9979 J3SI-1618-12 9/16 21/32 3/4 .5649 .5620 .6566 .6559 .5615 .5605 J350SI-0910-12
1 1 1/8 1 1.0041 1.0007 1.1255 1.1247 0.9991 0.9979 J3SI-1618-16 5/8 23/32 1/2 .6274 .6246 .7192 .7184 .6240 .6230 J350SI-1011-08
1 1/8 1 9/32 3/4 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 J3SI-1820-12 5/8 23/32 3/4 .6274 .6246 .7192 .7184 .6240 .6230 J350SI-1011-12
1 1/8 1 9/32 1 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 J3SI-1820-16 5/8 23/32 1 .6274 .6246 .7192 .7184 .6240 .6230 J350SI-1011-16
1 1/8 1 9/32 1 1/4 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 J3SI-1820-20 3/4 7/8 1/2 .7532 .7499 .8755 .8747 .7491 .7479 J350SI-1214-08
1 1/4 1 13/32 3/4 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 J3SI-2022-12 3/4 7/8 3/4 .7532 .7499 .8755 .8747 .7491 .7479 J350SI-1214-12
1 1/4 1 13/32 1 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 J3SI-2022-16 3/4 7/8 1 .7532 .7499 .8755 .8747 .7491 .7479 J350SI-1214-16
1 1/4 1 13/32 1 1/4 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 J3SI-2022-20 7/8 1 1/2 .8782 .8749 1.0005 .9997 .8741 .8729 J350SI-1416-08
1 1/2 1 21/32 1 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 J3SI-2426-16 7/8 1 3/4 .8782 .8749 1.0005 .9997 .8741 .8729 J350SI-1416-12
1 1/2 1 21/32 1 1/2 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 J3SI-2426-24 7/8 1 1 .8782 .8749 1.0005 .9997 .8741 .8729 J350SI-1416-16
1 5/8 1 25/32 1 1.6297 1.6258 1.7818 1.7808 1.6238 1.6222 J3SI-2629-16 1 1 1/8 1/2 1.0032 .9999 1.1255 1.1247 .9991 .9979 J350SI-1618-08
1 5/8 1 25/32 1 1/2 1.6297 1.6258 1.7818 1.7808 1.6238 1.6222 J3SI-2629-24 1 1 1/8 3/4 1.0032 .9999 1.1255 1.1247 .9991 .9979 J350SI-1618-12
1 3/4 1 15/16 1 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 J3SI-2831-16 1 1 1/8 1 1.0032 .9999 1.1255 1.1247 .9991 .9979 J350SI-1618-16
1 3/4 1 15/16 2 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 J3SI-2831-32 1 1/8 1 9/32 3/4 1.1279 1.1246 1.2818 1.2808 1.1238 1.1226 J350SI-1820-12
1 7/8 2 1/16 1 1.8796 1.8757 2.0633 2.0621 1.8737 1.8721 J3SI-3033-16 1 1/8 1 9/32 1 1.1279 1.1246 1.2818 1.2808 1.1238 1.1226 J350SI-1820-16
1 7/8 2 1/16 2 1.8796 1.8757 2.0633 2.0621 1.8737 1.8721 J3SI-3033-32 1 1/8 1 9/32 1 1/4 1.1279 1.1246 1.2818 1.2808 1.1238 1.1226 J350SI-1820-20
2 2 3/16 1 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 J3SI-3235-16 1 1/4 1 13/32 3/4 1.2537 1.2498 1.4068 1.4058 1.2488 1.2472 J350SI-2022-12
2 2 3/16 2 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 J3SI-3235-32 1 1/4 1 13/32 1 1.2537 1.2498 1.4068 1.4058 1.2488 1.2472 J350SI-2022-16
1 1/4 1 13/32 1 1/4 1.2537 1.2498 1.4068 1.4058 1.2488 1.2472 J350SI-2022-20
iglidur J350 Chapter „ Page 203 1 1/2 1 21/32 1 1.5037 1.4998 1.6568 1.6558 1.4988 1.4972 J350SI-2426-16
®
1 1/2 1 21/32 1 1/2 1.5037 1.4998 1.6568 1.6558 1.4988 1.4972 J350SI-2426-24
d1 d2 b1 d1 3) Housing hole Shaft size Part No. 1 5/8 1 25/32 1 1.6287 1.6248 1.7818 1.7808 1.6238 1.6222 J350SI-2629-16
max. min. max. min. max. min. 1 5/8 1 25/32 1 1/2 1.6287 1.6248 1.7818 1.7808 1.6238 1.6222 J350SI-2629-24
1/8 3/16 3/16 .1266 .1247 .1878 .1873 .1243 .1236 J350SI-0203-03 1 3/4 1 15/16 1 1.7536 1.7497 1.9381 1.9371 1.7487 1.7471 J350SI-2831-16
3/16 1/4 1/4 .1888 .1869 .2503 .2497 .1865 .1858 J350SI-0304-04 1 3/4 1 15/16 2 1.7536 1.7497 1.9381 1.9371 1.7487 1.7471 J350SI-2831-32
3/16 1/4 3/8 .1888 .1869 .2503 .2497 .1865 .1858 J350SI-0304-06 1 7/8 2 1/16 1 1.8747 1.8786 2.0633 2.0621 1.8737 1.8721 J350SI-3033-16
1/4 5/16 3/8 .2518 .2495 .3128 .3122 .2490 .2481 J350SI-0405-06 1 7/8 2 1/16 2 1.8747 1.8786 2.0633 2.0621 1.8737 1.8721 J350SI-3033-32
1/4 5/16 1/2 .2518 .2495 .3128 .3122 .2490 .2481 J350SI-0405-08 2 2 3/16 1 2.0040 1.9993 2.1883 2.1871 1.9981 1.9969 J350SI-3235-16
5/16 3/8 1/4 .3143 .3120 .3753 .3747 .3115 .3106 J350SI-0506-04 2 2 3/16 2 2.0040 1.9993 2.1883 2.1871 1.9981 1.9969 J350SI-3235-32
5/16 3/8 3/8 .3143 .3120 .3753 .3747 .3115 .3106 J350SI-0506-06
5/16 3/8 1/2 .3143 .3120 .3753 .3747 .3115 .3106 J350SI-0506-08 iglidur M250 Chapter „ Page 111
®
3/8 15/32 1/4 .3768 .3745 .4691 .4684 .3740 .3731 J350SI-0607-04
3/8 15/32 3/8 .3768 .3745 .4691 .4684 .3740 .3731 J350SI-0607-06 d1 d2 b1 d1 3) Housing hole Shaft size Part No.
3/8 15/32 1/2 .3768 .3745 .4691 .4684 .3740 .3731 J350SI-0607-08 max. min. max. min. max. min.
3/8 15/32 5/8 .3768 .3745 .4691 .4684 .3740 .3731 J350SI-0607-10 1/8 3/16 1/8 .1280 .1262 .1990 .1985 .1250 .1241 MSI-0203-02
3/8 15/32 3/4 .3768 .3745 .4691 .4684 .3740 .3731 J350SI-0607-12 1/8 3/16 1/4 .1280 .1262 .1990 .1985 .1250 .1241 MSI-0203-04
7/16 17/32 1/2 .4399 .4371 .5316 .5309 .4365 .4355 J350SI-0708-08 1/8 1/4 1/8 .1280 .1262 .2515 .2510 .1250 .1241 MSI-0204-02
7/16 17/32 3/4 .4399 .4371 .5316 .5309 .4365 .4355 J350SI-0708-12 1/8 1/4 3/16 .1280 .1262 .2515 .2510 .1250 .1241 MSI-0204-03
1/2 19/32 1/4 .5024 .4996 .5941 .5934 .4990 .4980 J350SI-0809-04 1/8 1/4 1/4 .1280 .1262 .2515 .2510 .1250 .1241 MSI-0204-04
1/2 19/32 3/8 .5024 .4996 .5941 .5934 .4990 .4980 J350SI-0809-06 1/8 1/4 3/8 .1280 .1262 .2515 .2510 .1250 .1241 MSI-0204-06
1/2 19/32 1/2 .5024 .4996 .5941 .5934 .4990 .4980 J350SI-0809-08 3/16 1/4 1/4 .1905 .1887 .2515 .2510 .1875 .1866 MSI-0304-04
1/2 19/32 5/8 .5024 .4996 .5941 .5934 .4990 .4980 J350SI-0809-10 3/16 1/4 3/8 .1905 .1887 .2515 .2510 .1875 .1866 MSI-0304-06

3) After press-fit. Testing methods u Page 61 ASEAN 09/2023 ASEAN 09/2023 3) After press-fit. Testing methods u Page 61
