Page 1120 - IGUS Bearing
P. 1120
Inch Inch
®
®
iglidur Imperial product range | iglidur | Sleeve bearings Imperial product range | iglidur | Sleeve bearings iglidur
®
®
form S form S
d1 d2 b1 d1 3) Housing hole Shaft size Part No. iglidur Q Chapter Page 491
®
max. min. max. min. max. min.
3/8 15/32 3/8 .3773 .3750 .4691 .4684 .3740 .3731 P210SI-0607-06 d1 d2 b1 d1 3) Housing hole Shaft size Part No.
3/8 15/32 1/2 .3773 .3750 .4691 .4684 .3740 .3731 P210SI-0607-08 max. min. max. min. max. min.
3/8 15/32 5/8 .3773 .3750 .4691 .4684 .3740 .3731 P210SI-0607-10 3/8 15/32 1/4 .3773 .3750 .4691 .4684 .3740 .3731 QSI-0607-04
3/8 15/32 3/4 .3773 .3750 .4691 .4684 .3740 .3731 P210SI-0607-12 3/8 15/32 3/8 .3773 .3750 .4691 .4684 .3740 .3731 QSI-0607-06
7/16 17/32 1/2 .4406 .4379 .5316 .5309 .4365 .4355 P210SI-0708-08 3/8 15/32 1/2 .3773 .3750 .4691 .4684 .3740 .3731 QSI-0607-08
7/16 17/32 3/4 .4406 .4379 .5316 .5309 .4365 .4355 P210SI-0708-12 7/16 17/32 1/2 .4406 .4379 .5316 .5309 .4365 .4355 QSI-0708-08
1/2 19/32 1/4 .5030 .5003 .5941 .5934 .4990 .4980 P210SI-0809-04 1/2 19/32 3/4 .5030 .5003 .5941 .5934 .4990 .4980 QSI-0809-12
1/2 19/32 3/8 .5030 .5003 .5941 .5934 .4990 .4980 P210SI-0809-06 5/8 23/32 3/4 .6280 .6253 .7192 .7184 .6240 .6230 QSI-1011-12
1/2 19/32 1/2 .5030 .5003 .5941 .5934 .4990 .4980 P210SI-0809-08 3/4 7/8 1/2 .7541 .7507 .8755 .8747 .7491 .7479 QSI-1214-08
1/2 19/32 5/8 .5030 .5003 .5941 .5934 .4990 .4980 P210SI-0809-10 3/4 7/8 3/4 .7541 .7507 .8755 .8747 .7491 .7479 QSI-1214-12
1/2 19/32 3/4 .5030 .5003 .5941 .5934 .4990 .4980 P210SI-0809-12 3/4 7/8 1 .7541 .7507 .8755 .8747 .7491 .7479 QSI-1214-16
1/2 19/32 1 .5030 .5003 .5941 .5934 .4990 .4980 P210SI-0809-16 7/8 1 1 .8791 .8757 1.0005 .9997 .8741 .8729 QSI-1416-16
9/16 21/32 1/2 .5655 .5627 .6566 .6559 .5615 .5605 P210SI-0910-08 1 1 1/8 1 1.0041 1.0007 1.1255 1.1247 .9991 .9979 QSI-1618-16
9/16 21/32 5/8 .5655 .5627 .6566 .6559 .5615 .5605 P210SI-0910-10 1 1 1/8 1 1/2 1.0041 1.0007 1.1255 1.1247 .9991 .9979 QSI-1618-24
9/16 21/32 3/4 .5655 .5627 .6566 .6559 .5615 .5605 P210SI-0910-12 1 1/8 1 9/32 1 1/2 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 QSI-1820-24
5/8 23/32 1/2 .6280 .6253 .7192 .7184 .6240 .6230 P210SI-1011-08 1 1/4 1 13/32 1 1/4 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 QSI-2022-20
5/8 23/32 3/4 .6280 .6253 .7192 .7184 .6240 .6230 P210SI-1011-12 1 1/4 1 13/32 1 1/2 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 QSI-2022-24
5/8 23/32 1 .6280 .6253 .7192 .7184 .6240 .6230 P210SI-1011-16 1 1/2 1 21/32 1 1/2 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 QSI-2426-24
3/4 7/8 1/2 .7541 .7505 .8755 .8747 .7491 .7479 P210SI-1214-08 1 5/8 1 25/32 1 1/4 1.6297 1.6258 1.7818 1.7808 1.6238 1.6222 QSI-2629-20
3/4 7/8 3/4 .7541 .7505 .8755 .8747 .7491 .7479 P210SI-1214-12 1 3/4 1 15/16 2 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 QSI-2831-32
3/4 7/8 1 .7541 .7505 .8755 .8747 .7491 .7479 P210SI-1214-16 2 2 3/16 3/4 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 QSI-3235-12
7/8 1 1/2 .8791 .8757 1.0005 .9997 .8741 .8729 P210SI-1416-08 2 2 3/16 1 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 QSI-3235-16
7/8 1 3/4 .8791 .8757 1.0005 .9997 .8741 .8729 P210SI-1416-12 2 2 3/16 1 1/2 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 QSI-3235-24
7/8 1 1 .8791 .8757 1.0005 .9997 .8741 .8729 P210SI-1416-16 2 2 3/16 2 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 QSI-3235-32
1 1 1/8 1/2 1.0041 1.0007 1.1255 1.1247 .9991 .9979 P210SI-1618-08 2 2 3/16 2 1/2 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 QSI-3235-40
1 1 1/8 3/4 1.0041 1.0007 1.1255 1.1247 .9991 .9979 P210SI-1618-12 2 1/4 2 7/16 2 2.2577 2.2531 2.4377 2.4365 2.2507 2.2489 QSI-3639-32
1 1 1/8 1 1.0041 1.0007 1.1255 1.1247 .9991 .9979 P210SI-1618-16
1 1/8 1 9/32 3/4 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 P210SI-1820-12 iglidur Q2 Chapter Page 477
®
1 1/8 1 9/32 1 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 P210SI-1820-16
1 1/8 1 9/32 1 1/4 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 P210SI-1820-20 d1 d2 b1 d1 3) Housing hole Shaft size Part No.
1 1/4 1 13/32 3/4 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 P210SI-2022-12 max. min. max. min. max. min.
1 1/4 1 13/32 1 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 P210SI-2022-16 1/8 3/16 3/16 .1269 .1251 .1878 .1873 .1243 .1236 Q2SI-0203-03
1 1/4 1 13/32 1 1/4 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 P210SI-2022-20 3/16 1/4 1/4 .1892 .1873 .2503 .2497 .1865 .1858 Q2SI-0304-04
1 1/2 1 21/32 1 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 P210SI-2426-16 3/16 1/4 3/8 .1892 .1873 .2503 .2497 .1865 .1858 Q2SI-0304-06
1 1/2 1 21/32 1 1/2 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 P210SI-2426-24 1/4 5/16 3/8 .2521 .2498 .3128 .3122 .2490 .2481 Q2SI-0405-06
1 5/8 1 25/32 1 1.6297 1.6258 1.7818 1.7808 1.6238 1.6222 P210SI-2629-16 1/4 5/16 1/2 .2521 .2498 .3128 .3122 .2490 .2481 Q2SI-0405-08
1 5/8 1 25/32 1 1/2 1.6297 1.6258 1.7818 1.7808 1.6238 1.6222 P210SI-2629-24 5/16 3/8 1/4 .3148 .3125 .3753 .3747 .3115 .3106 Q2SI-0506-04
1 3/4 1 15/16 1 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 P210SI-2831-16 5/16 3/8 3/8 .3148 .3125 .3753 .3747 .3115 .3106 Q2SI-0506-06
1 3/4 1 15/16 2 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 P210SI-2831-32 5/16 3/8 1/2 .3148 .3125 .3753 .3747 .3115 .3106 Q2SI-0506-08
1 7/8 2 1/16 1 1.8796 1.8757 2.0633 2.0621 1.8737 1.8721 P210SI-3033-16 3/8 15/32 1/4 .3773 .3750 .4691 .4684 .3740 .3731 Q2SI-0607-04
1 7/8 2 1/16 2 1.8796 1.8757 2.0633 2.0621 1.8737 1.8721 P210SI-3033-32 3/8 15/32 3/8 .3773 .3750 .4691 .4684 .3740 .3731 Q2SI-0607-06
2 2 3/16 1 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 P210SI-3235-16 3/8 15/32 1/2 .3773 .3750 .4691 .4684 .3740 .3731 Q2SI-0607-08
2 2 3/16 2 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 P210SI-3235-32 3/8 15/32 5/8 .3773 .3750 .4691 .4684 .3740 .3731 Q2SI-0607-10
3) After press-fit. Testing methods u Page 61 3/8 15/32 3/4 .3773 .3750 .4691 .4684 .3740 .3731 Q2SI-0607-12
.5309
.5316
Q2SI-0708-08
.4355
.4365
.4379
17/32
7/16
.4406
1/2
ASEAN 09/2023 ASEAN 09/2023 3) 7/16 17/32 3/4 .4406 .4379 .5316 .5309 .4365 .4355 Q2SI-0708-12
After press-fit. Testing methods u Page 61
