iglidur iglidur PRT | Product range iglidur PRT | Product range New iglidur
®
®
PRT PRT
Installation solutions - type 04 Hygienic design
Order key

Type Size Options

With outer With large outer
spacer ring support ring
Slewing ring Inner Ø [mm] ● With certified hygienic design screws machine construction and designed to your requirements.
H ● Easy to clean according to hygienic design guidelines The slewing rings with hygienic design are used in special

h1 Type Thread ● Low dead space design, even on the seals Contact us!

S1 ● FDA-compliant seals u www.igus-asean.com/prt-enquiry
T2
D D1 d1 d d2 ● Maintenance-free and wear-resistant
T1
● Easy installation
● Replaceable sliding elements
K1

S2 h
Dimensions [mm]

D D1 d1 d d2 H h1 h T1 T2 S1 S2 K1 Part No.
for screw
With M4 thread in outer ring
80 70 30 20 60 16 – 6 8 × 45° 8 × 45° M4 M4 Ø 4.5 PRT-04-20-M4 New
90 80 40 30 70 16 – 6 8 × 45° 8 × 45° M4 M4 Ø 4.5 PRT-04-30-M4 New
110 100 60 50 90 16 – 6 8 × 45° 8 × 45° M4 M4 Ø 4.5 PRT-04-50-M4
120 110 70 60 100 16 – 6 8 × 45° 8 × 45° M4 M4 Ø 4.5 PRT-04-60-M4
160 150 110 100 140 16 – 6 8 × 45° 8 × 45° M4 M4 Ø 4.5 PRT-04-100-M4
210 200 160 150 190 16 – 6 16 × 22.5° 16 × 22.5° M4 M4 Ø 4.5 PRT-04-150-M4
260 250 210 200 240 16 – 6 16 × 22.5° 16 × 22.5° M4 M4 Ø 4.5 PRT-04-200-M4
360 350 310 300 340 16 – 6 16 × 22.5° 16 × 22.5° M4 M4 Ø 4.5 PRT-04-300-M4 Easy to clean: PRT hygienic design for the beverage PRT made of stainless steel with hygienic design
With enlarged outer ring industry seals
80 70 30 20 60 16 – 6 8 × 45° 6 × 60° M4 Ø 4.5 Ø 4.5 PRT-04-20-G New
100 91 40 30 70 16 – 6 8 × 45° 8 × 45° M4 Ø 4.5 Ø 4.5 PRT-04-30-G New If you cannot find the right product in our constantly growing
150 135 60 50 90 16 – 6 8 × 45° 16 × 22.5° M4 Ø 6.6 Ø 4.5 PRT-04-50-G range, simply contact us. We would be happy to help you
160 145 70 60 100 16 – 6 8 × 45° 20 × 18° M4 Ø 5.5 Ø 4.5 PRT-04-60-G designing your slewing ring bearing.
185 170 110 100 140 16 – 6 8 × 45° 16 × 22.5° M4 Ø 4.5 Ø 4.5 PRT-04-100-G
250 235 160 150 190 16 – 6 16 × 22.5° 16 × 22.5° M4 Ø 4.5 Ø 4.5 PRT-04-150-G By entering a few parameters regarding installation space,
300 285 210 200 240 16 – 6 16 × 22.5° 16 × 22.5° M4 Ø 5.5 Ø 4.5 PRT-04-200-G load, speed and environment, we configure the right bearing
450 430 310 300 340 16 – 6 16 × 22.5° 16 × 22.5° M4 Ø 9.0 Ø 4.5 PRT-04-300-G for your application.
With outer spacer ring
80 70 30 20 60 17 1 12 8 × 45° 8 × 45° M4 Ø 4.5 Ø 4.5 PRT-04-20-DRI New
90 80 40 30 70 17 1 12 8 × 45° 8 × 45° M4 Ø 4.5 Ø 4.5 PRT-04-30-DRI New
110 100 60 50 90 17 1 12 8 × 45° 8 × 45° M4 Ø 4.5 Ø 4.5 PRT-04-50-DRI
120 110 70 60 100 17 1 12 8 × 45° 8 × 45° M4 Ø 4.5 Ø 4.5 PRT-04-60-DRI
160 150 110 100 140 17 1 12 8 × 45° 8 × 45° M4 Ø 4.5 Ø 4.5 PRT-04-100-DRI
210 200 160 150 190 17 1 12 16 × 22.5° 16 × 22.5° M4 Ø 4.5 Ø 4.5 PRT-04-150-DRI
260 250 210 200 240 17 1 12 16 × 22.5° 16 × 22.5° M4 Ø 4.5 Ø 4.5 PRT-04-200-DRI
360 350 310 300 340 17 1 12 16 × 22.5° 16 × 22.5° M4 Ø 4.5 Ø 4.5 PRT-04-300-DRI ASEAN 09/2023 ASEAN 09/2023

730 Online tools and more information u www.igus-asean.com/prt 3D CAD files, prices and delivery time online u www.igus-asean.com/prt 731
