drylin  R shaft guides | Advantages                                                                                      drylin  R shaft guides | Product overview
                   ®
                                                                                                                                           ®
        Extremely wear-resistant, robust in challenging environments and lightweight                                             Dimensions correspond to standard for recirculating ball bearings



             Dimensions identical to                          Lubrication-free shaft

                                                              guides - drylin  R
                                                                                              ®
                 linear ball bearings                         drylin  R shaft guides are based on extremely

                                                                    ®
                     Hard-anodised aluminium shafts guarantee   wear-resistant polymers specially developed
                                  optimum running properties  for the linear technology. The dimensions are                      Liners and press-fit bearings                        Linear plain bearings
                                                              compatible with standard ball bearings. The                                         ®
                                                              special geometry guarantees reliability even in                    ● 	Made from iglidur  high-performance polymers      ● 	Dimensionally interchangeable with standard
                                                              extreme environments.                                              ● 	Easy to fit                                          recirculating ball bearings
                             Shafts made from steel, stainless   ● 	100% lubrication-free                                        ● 	Unaffected by dirt and dust                       ● 	Extremely lightweight solid plastic bearing
                                         steel or carbon fibre  ● 	Dimensionally interchangeable with standard                   ● 	Low coefficient of friction, optimised wear quality  ● 	Aluminium and stainless steel adapters equipped with
                                                                                                                                                                                              ®
                                                                recirculating ball bearings                                      u Page 188                                              iglidur  liners
                                                              ● 	 Large variety of choice in housing shapes                                                                           u Page 210
                                       Shafts and supported    ● 	 Shafts, shaft end blocks and accessories
                                             shafts available   available from stock
                                                              ● 	Replaceable liners
                                                              ● 	Stainless steel housings available
                               Linear adapter made from solid
                                         plastic or aluminium  Typical application areas
                                                              ● 	Agricultural machinery
                                                              ● 	Automotive
                                                              ● 	Medical technology
                                Complete housing made from    ● 	Facade construction
                                         anodised aluminium   ● 	Packaging industry

                                                                    Available from stock
                                                                    Detailed information about delivery time online.             W360CM linear plain bearing (precision)              Linear bearings and pillow blocks, open/
                                                                                                                                 ● 	High rigidity                                     closed design
                                                                    Price breaks online                                          ● 	Low bearing clearance                             ● 	For unsupported shafts u Page 268
                                                                    No minimum order value. No minimum order quantity            ● 	Linear bearings or flanged bearings               ● 	For supported shafts u Page 269
                                  drylin  liners made from five                                                                  u Page 218                                             	Fixed bearing/floating bearing/tandem bearing/
                                      ®
                               different lubrication-free iglidur     Max. +200°C                                                                                                     ●  clearance adjustment
                                                         ®
                                  high-performance polymers
                                                                    Min. -40°C                                                                                                        u Page 237

                                                                    Up to Ø 60mm
                                                                    More dimensions upon request.


                                    Hard-anodised aluminium         Imperial dimensions available
                                          tubes - lightweight       u From page 746

                                                                    Service life calculation
                                                                    u www.igus-asean.com/drylin-expert
                                                                                                                                 Flanged linear plain bearings                        Quad block
                                                                                                                                                                 ®
                                                                                                                                 ● 	Pre-assembled housings with drylin  liners        ● 	Closed and open design
                                                                                                                                 ● 	Round or square flange                            ● 	 Torque-resistant quad block housing with
                                                                                                                                                                                         four linear adapters
        Cleanroom certificated     Free from toxins           ESD-compatible                                                     ● 	Tandem flange housing for additional stability    ● 	Also available as tandem housing
                                                                                                                                 u Page 242
        IPA Fraunhofer             2011/65/EU (RoHS)          (electrostatic discharge)                            ASEAN 09/2023  ASEAN 09/2023                                       u Page 252
