drylin R shaft guides | Application examples drylin R shaft guides | Online tools
®
®
Expert for linear guides: System selection
and service life calculation with CAD
Configure and calculate the service life of linear
bearings - constantly expanded by new sizes and
Cutting table products
drylin R linear plain bearings on supported aluminium Easily calculate the service life of your required linear guide
®
shafts are used in this grinder to guide the cutting and configure with a few clicks. Select a drylin system
®
table. The drylin components stand for extreme dirt and add the relevant environmental parameters. Select the
®
resistance, accurate guidance and smooth operation. bearing size, carriage, number and position. Then enter the
distance between the rails and the mounting. Define more
relevant parameter of the guidance and select a rail length.
The results are displayed.
u www.igus-asean.com/drylin-expert
Download the online tool
app now
Angle stop in sawmill
Saw mill: linear guide with iglidur J plastic liner for the drylin CAD configurator: Generate
®
®
angle stops.iglidur J liners are best suited for most complete 3D models for drylin linear
®
®
linear applications due to their low wear and low friction technology according to your specifications
properties.
The igus CAD online configurator gives you the ability to
®
design and save your linear guide as a system, individual
components directly as a 3D model in all commonly used
formats, or to have these sent by e-mail - free of charge
and without registration.
u www.igus-asean.com/drylin-CAD
More information about the products can be
found in the igus download area
®
Concrete pipe cutter
The machine now runs entirely free of troubles for ● Assembly instructions
multiple years with drylin RJUM-01 linear bearings ● Assembly videos
®
despite the extremely heavy-duty operation. ● System design
● Catalogues
u www.igus-asean.com/igus-downloads
