drylin W profile guides | Application examples drylin W profile guides | Online tools
®
®
Expert for linear guides: System selection
and service life calculation with CAD
Configure and calculate the service life of linear bearings -
constantly expanded by new sizes and products
Easily calculate the service life of your required linear guide
and configure with a few clicks. Select a drylin system
®
Pick & place
drylin linear bearings enable precise positioning at and add the relevant environmental parameters. Select the
®
high speeds. Unlike conventional bearings, they do bearing size, carriage, number and position. Then enter the
not require lubrication and are corrosion free. distance between the rails and the mounting. Define more
relevant parameter of the guidance and select a rail length.
The results are displayed.
u www.igus-asean.com/drylin-expert
Download the online tool
app now
3D printer
®
Lightweight due to the use of plastic and aluminium with drylin CAD configurator: Generate
®
a corrosion-free coating, the guides in the drylin range complete 3D models for drylin linear
®
impress with their quiet and precise running. technology according to your specifications
The igus CAD online configurator gives you the ability to
®
design and save your linear guide as a system, individual
components directly as a 3D model in all commonly used
formats, or to have these sent by e-mail - free of charge
and without registration.
u www.igus-asean.com/drylin-CAD
More information about the products can be
found in the igus download area
®
Casting machine Assembly instructions
The closing mechanism on this casting machine is ● Assembly videos
subjected to high temperatures and dirt. To make it ● System design
as durable as possible despite this, it is mounted with ● Catalogues
a drylin W profile guide. ●
®
u www.igus-asean.com/igus-downloads
