drylin  W profile guides | Advantages                                                                                    drylin  W profile guides | Products overview
                   ®
                                                                                                                                           ®
        Lubrication-free, light, quiet, long service life, cost-effective                                                        Profile guides for almost unlimited design freedom



                                 Superior operating properties   Lubrication-free linear
                                 by combining iglidur  bearing
                                                  ®
                                                                                               ®
                              elements and anodised rails with   system - drylin  W
                                         round shaft profiles
                                                              drylin  W profile guides are a cost-effective pre-
                                                                    ®
                                                              assembled system. The design allows extremely
                                                              high flexibility in the construction and installation
                                     Corrosion-resistant with    due to the use of individual or double rails. Hard-             Individual components: Pillow blocks                 Single components: Single and double rails
                               hard-anodised running surface                                                                     ● 	Material: Zinc die-casting, aluminium or stainless steel  ● 	Material: Aluminium, hard-anodised
                                                              anodised aluminium is used as rail material and
                                                              provides the best friction and wear results. The                   ● 	Round or square design ®                          ● 	Design freedom
                                                              absence of lubrication makes the profile guide                     ● 	Liners made from iglidur  high-performance polymers  ● 	316 stainless steel rails
                                                              system extremely insensitive to dirt and, due to                   u From page 64                                       u From page 62
                                             Quiet operation
                                                              its cleanliness, it is also suitable for applications
                                                              in clean and hygienic environments.
                                                              ● 	Easy installation, maintenance-free
                                                              ● 	Resistant to dirt thanks to dry operation
                                               Clean as no      	Lightweight and quiet
                                         lubrication required  ●
                                                              ● 	 Square rail with floating bearing function for
                                                                90° installation
                                                              ● 	Bearing with manual clearance adjustment
                                          Lightweight due to    available
                                          the use of plastics
                                             and aluminium                                                                       Assembled systems: Complete carriages                Linear carriage with optional features
                                                              Typical application areas                                          ● 	Pre-assembled                                     ● 	Carriage with wear measurement
                                                              ● 	Agricultural machinery                                          ● 	Variable lengths and widths                       ● 	Carriage with hand lever
                                                              ● 	Automotive                                                      ● 	Mono-slide carriage made from aluminium           ● 	Clip carriage with/without manual clamp
                                                              ● 	Medical technology
                                Smooth operation with sliding   	Packaging industry                                              u From page 82                                       ● 	Locking carriages
                                         elementsmade from    ● 	Furniture                                                                                                            u From page 94
                                      lubrication-free iglidur     ●
                                                         ®
                                  high-performance polymers
                                                                    Available from stock
                                                                    Detailed information about delivery time online.
                                     Maintenance-free due to
                                        integrated lubricants
                                                                    Price breaks online
                                                                    No minimum order value. No minimum order quantity


                                                                    Max. +200°C                                                  Hybrid guides                                        Accessories
                                                                    Min. -40°C
                                                                                                                                 ● 	Linear housing with integrated single or double roller  ● 	Manual clamp for single bearing housing and
                                         Profiles with various      Carriage lengths: 60-250mm                                   ● 	Low drive forces                                     complete carriages
                                geometric designs, installation     Carriage widths:   54-195mm                                  ● 	Available as single housing or complete carriage  ● 	End caps for high profile rails
                                        sizes and clearances                                                                     u From page 107                                      u From page 124
                                                                    Rail length:        up to 4,000mm

                                                                    Service life calculation                                     Based on drylin  W
                                                                                                                                                  ®
                                                                    u www.igus-asean.com/drylin-expert
                                                                                                                                                      Measuring systems                                       Linear modules
                                                                                                                                                      u From page 301                                         SLW/SAW/GRW/ZLW
                                                                                                                                                                                                              uFrom page 538
