drylin E drylin drive technology | Accessories | Product range drylin drive technology | Accessories | Product range drylin E
®
®
®
accessories accessories
Using motor flange for stepper and DC motors Spacer - height compensation for SLW/SHT linear modules

LK
● 2 base plate lengths for each NEMA motor flange;
others upon request
®
● Suitable for drylin coupling u Page 669
Motor type NEMA XXX
Dimensions [mm] s
Part No. Matching linear modules Base plate Motor flange The spacer is an aluminium standoff that brings the selected
AG LG LK AM HM LM f drylin linear unit to a height that matches your NEMA H
®
MF-0630-NEMA17-S ZLW-0630 12 99.5 35.5 10 53 42 7 stepper motor. An attachment feature for proximity switches
MF-0630-NEMA23-S ZLW-0630 12 99.5 35.5 10 59 56 14 is already integrated. Retro-fitting is also possible.
MF-1040-NEMA17-S ZLW-1040 17 119 35 10 63 44 – ● Adapter kit contains two spacers for connection of a c
MF-1040-NEMA23-S ZLW-1040 17 119 35 10 70.7 56.4 7 linear module
MF-1040-NEMA34-L ZLW-1040 17 138 54 10 85 85 20.5
MF-1660-NEMA34-S ZLW-1660 15 166 52 10 86 86 – c1
MF-2260-NEMA23-S ZAW-1040 10 108 35 10 70.7 56.4 – B
MF-0630-DC0310 ZLW-0630 12 99.5 35.5 10 53 42 7
MF-1040-DC0310 ZLW-1040 17 119 35 10 63 44 –
MF-1040-DC0350 ZLW-1040 17 119 35 10 63 44 – Part No. Suitable for linear module A
AK-0001 SLW-1040
AK-0002 SLW-1080
AK-0003 SLW-1660
AK-0004 SLW-2080
LM b AK-0027 SHT-08
AK-0006 SHT-12
ha
AK-0007 SHT-20
f
AK-0008 SHT-30
The motor flange, sometimes called motor enclosure, HM AM AK-0009 SLW-25120
encloses and protects the coupling and provides the LG
matching mounting dimensions for your NEMA motor.
● Suitable for drylin coupling u Page 669
®
Dimensions [mm] Dimensions [mm]
Part No. Matching linear modules LG AM HM LM b f ha Part No. A B H c c1 Ø s
MF-1123-NEMA17 SAW/SLW-BB-0630 45 – 43 43 43 – 21.5 ±0.1 +0.2
MF-2040-NEMA17 SAW/SLW-1040-AL, SHT-12 47 12 56 56 56 – 21.5 AK-0001 74 32.0 21.0 60 11.0 6.2
MF-2040-NEMA23-S SAW/SLW-1040-AL, SHT-12/20 48 13 56 56 56 – 28 AK-0002 108 32.0 21.0 94 11.0 6.2
MF-3648-NEMA23 SHT-20, SHT-BB-20 56 13 56 56 56 – 28 AK-0003 104 -0.2 35.0 24.5 84 12.5 8.1
SLW-1660/2080, AK-0004 134 38.0 20.0 116 14.0 9.0
MF-3648-NEMA34 65 10 86 86 46 20 43
SLW-BB-1660/2080 AK-0027 65 25.5 13.0 52 7.75 5.5
MF-3648-NEMA34-XL SHT-30, SHT-BB-30 76 10 86 86 56 15 43 AK-0006 85 40.0 17.5 70 15.0 6.2
MF-1123-DC0310 SAW/SLW-BB-0630 45 – 43 43 43 – 21.5 AK-0007 130 46.0 22.0 108 18.0 10.5
MF-2040-DC0310 SAW/SLW-1040-AL, SHT12 47 12 43 43 43 – 21.5 AK-0008 180 60.0 10.0 150 ±0.2 25.0 13.5
MF-2040-DC0350 SAW/SLW-1040-AL, SHT12 47 12 43 43 43 – 21.5 ASEAN 09/2023 ASEAN 09/2023 AK-0009 200 45.0 16.0 173 ±0.2 17.5 13.5

680 Online tools and more information u www.igus-asean.com/drylinE-accessories 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinE-accessories 681
