CF887 PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF887
PVC Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PVC
15 x d ® Oil resistance none 1 2 3 4 highest 15 x d
Servo cable | PVC | chainflex CF887 Class 3.1.1.1 Torsion none 1 2 3 4 ±360°

5,000,000 15 x d 10m Properties and approvals According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame
Flame-retardant
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®

Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
z For flexing applications 1992)
z PVC outer jacket UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
z Shielded service life calculator based on 2 billion test cycles per year"
z Flame-retardant UL/CSA AWM See data sheet for details  www.igus-asean.com/CF887

NFPA Following NFPA 79-2018, chapter 12.9
Dynamic information
Bend radius e-chain linear minimum 15 x d EAC Certificate No. RU C-DE.ME77.B.00302/19
®
flexible minimum 12 x d
fixed minimum 8 x d REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
®
Temperature e-chain linear +5°C up to +70°C
flexible -5°C up to +70°C (following DIN EN 60811-504) Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
fixed -15°C up to +70°C (following DIN EN 50305)
v max. unsupported 3m/s CE Following 2014/35/EU

a max. 20m/s² UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)

Travel distance Unsupported travels up to 10m, Class 1
Guaranteed service life (details see page 28-29)
Cable structure Double strokes* 1 million 3 million 5 million

Conductor Conductor consisting of bare copper wires (according to DIN EN 60228). Temperature, R min. R min. R min.
from/to [°C] [factor x d] [factor x d] [factor x d]
Core insulation Mechanically high-quality, especially low-capacitance TPE mixture. +5/+15 17.5 18.5 19.5
+15/+60 15 16 17
Core structure Power cores and control pair elements wound together in an optimised pitch +60/+70 17.5 18.5 19.5
length. * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Core identification Power cores: Black cores with white numbers, one green-yellow core. Typical application areas
1. Core: U / L1 / C / L+ 2. Core: V / L2 3. Core: W / L3 / D / L- z For flexing applications, Class 3
1 control pair: Black cores with white numbers. z Especially for unsupported travels, Class 1
1. Control core: 5 2. Control core: 6 z Without influence of oil, Class 1
2 control pairs: Black cores with white numbers. z No torsion, Class 1
1. Control core: 5 2. Control core: 6 z Preferably indoor applications
3. Control core: 7 4. Control core: 8 z Wood/stone processing, packaging industry, feeding, handling, adjusting devices
Element shield Foil taping of optimised, bending-resistant foil shield.
Number of cores and conductor Outer diameter Copper
Part No. Weight
Overall shield Braiding made of tinned copper wires. nominal cross section (d) max. index
Coverage approx. 60% optical [mm²] [mm] [kg/km] [kg/km]
®
Outer jacket Low-adhesion PVC mixture, adapted to suit the requirements in e-chains . 1 control pair shielded
Colour: Pastel orange (similar to RAL 2003) CF887.07.05.02.01 (4G0.75+(2x0.5)C)C 10.0 69 119
CF887.15.15.02.01 (4G1.5+(2x1.5)C) 12.5 124 200
Electrical information CF887.25.15.02.01 (4G2.5+(2x1.5)C)C 13.5 182 254
Nominal voltage 600/1,000V (following DIN VDE 0298-3) CF887.40.15.02.01 (4G4.0+(2x1.5)C)C 14.5 236 340
1,000V (following UL) 2 control pairs shielded (4G1.0+2x(2x0.75)C) 11.5 110 184
CF887.10.07.02.02
4,000V (following DIN EN 50395)
Testing voltage
Example image CF887.15.15.02.02 (4G1.5+2x(2x1.5)C)C 13.5 164 253
14.5
(4G2.5+2x(2x1.5)C)C
325
217
CF887.25.15.02.02
EPLAN download, configurators  www.igus-asean.com/CF887 Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core
