CF270.UL.D PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF270.UL.D
PUR Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PUR
10 x d ® Oil resistance none 1 2 3 4 highest 10 x d
Servo cable | PUR | chainflex CF270.UL.D Class 4.2.3.1 Torsion none 1 2 3 4 ±360°

10 million 10 x d 10m Properties and approvals Medium
UV resistance
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®

Oil resistance Oil-resistant (following DIN EN 50363-10-2), Class 3
z For medium duty applications z Notch-resistant
z PUR outer jacket z Flame-retardant Offshore MUD-resistant following NEK 606 - status 2016
z Shielded z Hydrolysis and microbe-resistant
z Oil-resistant and coolant-resistant z PVC and halogen-free Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame

Dynamic information Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
®
Bend radius e-chain linear minimum 10 x d 1992)
flexible minimum 8 x d Halogen-free Following DIN EN 60754
fixed minimum 5 x d
®
Temperature e-chain linear -25°C up to +80°C UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
flexible -40°C up to +80°C (following DIN EN 60811-504) service life calculator based on 2 billion test cycles per year"
fixed -50°C up to +80°C (following DIN EN 50305) UL/CSA AWM See data sheet for details  www.igus-asean.com/CF270ULD
v max. unsupported 10m/s
gliding 2m/s NFPA Following NFPA 79-2018, chapter 12.9
a max. 50m/s²
EAC Certificate No. RU C-DE.ME77.B.00863/20
Travel distance Unsupported travels and up to 10m for gliding applications, Class 2
REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
Cable structure
Conductor Stranded conductor in bending-resistant version consisting of bare copper Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
wires (following DIN EN 60228).
Core insulation Mechanically high-quality, especially low-capacitance XLPE mixture. Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
CF77.UL.05.12.D - tested by IPA according to standard DIN EN ISO 14644-1
Core structure Power cores and control pair elements wound with a short pitch length around DESINA According to VDW, DESINA standardisation
a high tensile strength centre element.
Core identification Power cores: Black cores with white numbers, one green-yellow core. CE Following 2014/35/EU
1. Core: U / L1 / C / L+ 2. Core: V / L2 3. Core: W / L3 / D / L-
1 control pair: Black cores with white numbers. UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
1. Control core: 4 2. Control core: 5
2 control pairs: Black cores with white numbers.
1. Control core: 5 2. Control core: 6 Guaranteed service life (details see page 28-29)
3. Control core: 7 4. Control core: 8 Double strokes* 5 million 7.5 million 10 million

Element shield Bending-resistant braiding made of tinned copper wires. Temperature, R min. R min. R min.
from/to [°C] [factor x d] [factor x d] [factor x d]
Intermediate layer Foil taping over the outer layer. -25/-15 12.5 13.5 14.5
-15/+70 10 11 12
Overall shield Bending-resistant braiding made of tinned copper wires. +70/+80 12.5 13.5 14.5
Coverage linear approx. 55%, optical approx. 80% * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Outer jacket Low-adhesion, halogen-free, highly abrasion resistant PUR mixture, adapted to
®
suit the requirements in e-chains (following DIN EN 50363-10-2) Typical application areas
Colour: Pastel orange (similar to RAL 2003) z For medium duty applications, Class 4
Electrical information z Unsupported travels and up to 10m for gliding applications, Class 2
Nominal voltage 600/1,000V (following DIN VDE 0298-3) z Almost unlimited resistance to oil, Class 3
1,000V (following UL)
No torsion, Class 1
Example image Testing voltage 4,000V (following DIN EN 50395) z Indoor and outdoor applications without direct sun radiation
z
Machining units/machine tools, low temperature applications
z
