CF280.UL.H PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF280.UL.H
PUR New Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PUR
10 x d ® Oil resistance none 1 2 3 4 highest 10 x d
Hybrid servo cable | PUR | chainflex CF280.UL.H Class 4.2.3.1 Torsion none 1 2 3 4 ±360°

10 million 10 x d 10m Properties and approvals Medium
UV resistance
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®

Oil resistance Oil-resistant (following DIN EN 50363-10-2), Class 3
z For medium duty applications New cable
z PUR outer jacket Offshore MUD-resistant following NEK 606 - status 2016
z Shielded suitable for
z Oil-resistant and coolant-resistant Bosch Rexroth Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame
z Flame-retardant ctrlX DRIVE
z PVC and halogen-free Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
z Notch-resistant 1992)
z Hydrolysis and microbe-resistant Halogen-free Following DIN EN 60754

Dynamic information UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
Bend radius e-chain linear minimum 10 x d service life calculator based on 2 billion test cycles per year"
®
flexible minimum 8 x d UL/CSA AWM See data sheet for details  www.igus-asean.com/CF280ULH
fixed minimum 5 x d
®
Temperature e-chain linear -25°C up to +80°C NFPA Following NFPA 79-2018, chapter 12.9
flexible -40°C up to +80°C (following DIN EN 60811-504)
fixed -50°C up to +80°C (following DIN EN 50305) EAC Certificate No. RU C-DE.ME77.B.00863/20
v max. unsupported 10m/s
gliding 2m/s REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
a max. 50m/s²
Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
Travel distance Unsupported travels and up to 10m for gliding applications, Class 2
Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
Cable structure CF77.UL.05.12.D - tested by IPA according to standard DIN EN ISO 14644-1
Conductor Stranded conductor in bending-resistant version consisting of bare copper DESINA According to VDW, DESINA standardisation
wires (following DIN EN 60228).
Core insulation Mechanically high-quality, especially low-capacitance XLPE mixture. CE Following 2014/35/EU

Core structure Power cores and control pair elements wound with a short pitch length around UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
a high tensile strength centre element.
Core identification According to Servo-Hybrid specification. Info As hybrid cables are always designed for specific drive systems, additional
Current data sheet  www.chainflex.eu/CF220ULH electrotechnical data may need to be considered. You will find more informa-
Element shield Bending-resistant braiding made of tinned copper wires. tion in the latest data sheet for the cable series.

Intermediate layer Foil taping over the outer layer. Guaranteed service life (details see page 28-29)

Double strokes* 5 million 7.5 million 10 million
Overall shield Bending-resistant braiding made of tinned copper wires. Temperature, R min. R min. R min.
Coverage linear approx. 55%, optical approx. 80% from/to [°C] [factor x d] [factor x d] [factor x d]
Outer jacket Low-adhesion, halogen-free, highly abrasion resistant PUR mixture, adapted to -25/-15 12.5 13.5 14.5
®
suit the requirements in e-chains (following DIN EN 50363-10-2) -15/+70 10 11 12
Colour: Pastel orange (similar to RAL 2003) +70/+80 12.5 13.5 14.5
Variants  Product range table * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Electrical information Typical application areas
Nominal voltage 600/1,000V (following DIN VDE 0298-3) z For medium duty applications, Class 4
Unsupported travels and up to 10m for gliding applications, Class 2
1,000V (following UL)
z
Example image Testing voltage Variants  Product range table z Almost unlimited resistance to oil, Class 3
4,000V (following DIN EN 50395)
No torsion, Class 1
z
ASEAN2023 ASEAN2023 z Indoor and outdoor applications without direct sun radiation
Machining units/machine tools, low temperature applications
z
