CF30 PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF30
PVC Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PVC
7.5 x d ® Oil resistance none 1 2 3 4 highest 7.5 x d
Motor cable | PVC | chainflex CF30 Class 5.5.2.2 Torsion none 1 2 3 4 ±360°

10 million 7.5 x d 100m Properties and approvals Medium
UV resistance
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®

Oil resistance Oil-resistant (following DIN EN 50363-4-1), Class 2
z For heavy duty applications
z PVC outer jacket Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame
z Oil-resistant
z Flame-retardant Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
1992)
UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
Dynamic information service life calculator based on 2 billion test cycles per year"
Bend radius e-chain linear minimum 7.5 x d UL/CSA AWM See data sheet for details www.igus-asean.com/CF30
®
flexible minimum 6 x d
fixed minimum 4 x d NFPA Following NFPA 79-2018, chapter 12.9
Temperature e-chain linear +5°C up to +70°C
®
flexible -5°C up to +70°C (following DIN EN 60811-504) EAC Certificate No. RU C-DE.ME77.B.00863/20
fixed -15°C up to +70°C (following DIN EN 50305)
v max. unsupported 10m/s REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
gliding 5m/s
a max. 80m/s² Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)

Travel distance Unsupported travels and up to 100m for gliding applications, Class 5 Cleanroom According to ISO Class 2. The outer jacket material of this series complies with
CF5.10.07 - tested by IPA according to standard DIN EN ISO 14644-1
Torsion Torsion ±90°, with 1m cable length, Class 2 CE Following 2014/35/EU

Cable structure UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
Conductor Cores <10mm²: Stranded conductor in especially bending-resistant version
consisting of bare copper wires (following DIN EN 60228).
Cores ≥ 10mm²: Conductor cable consisting of pre-leads (following DIN EN 60228). Guaranteed service life (details see page 28-29)
Core insulation Mechanically high-quality, especially low-capacitance XLPE mixture. Double strokes* 5 million 7.5 million 10 million

Temperature, R min. R min. R min.
Core structure Cores wound with a short pitch length around a high tensile strength centre from/to [°C] [factor x d] [factor x d] [factor x d]
element. +5/+15 10 11 12
Core identification Black cores with white numbers, one green-yellow core. +15/+60 7.5 8.5 9.5
1. Core: U / L1 / C / L+ 2. Core: V / L2 +60/+70 10 11 12
3. Core: W / L3 / D / L- 4. Core: 4 / N * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Outer jacket Low-adhesion, oil-resistant PVC mixture, adapted to suit the requirements in
®
e-chains (following DIN EN 50363-4-1). Typical application areas
Colour: jet black (similar to RAL 9005) z For heavy-duty applications, Class 5
CFRIP ® Strip cables faster: a tear strip is moulded into the outer jacket z Unsupported travels and up to 100m for gliding applications, Class 5
Video  www.igus-asean.com/CFRIP z Light oil influence, Class 2
Electrical information z Torsion ±90°, with 1m cable length, Class 2
Nominal voltage 600/1,000V (following DIN VDE 0298-3) z Preferably indoor applications, but also outdoor ones at temperatures > 5 °C
1,000V (following UL) z Storage and retrieval units, machining units/packaging machines, quick handling, indoor cranes
Testing voltage 4,000V (following DIN EN 50395)

Example image

EPLAN download, configurators  www.igus-asean.com/CF30
