CF210.UL PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CF210.UL
PVC Travel distance unsupported 1 2 3 4 5 6 ≥ 400m PVC
10 x d ® Oil resistance none 1 2 3 4 highest 10 x d
Motor cable | PVC | chainflex CF210.UL Class 4.2.2.1 Torsion none 1 2 3 4 ±360°

10 million 10 x d 10m Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®
Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
1992)
z For medium duty applications z Flame-retardant UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
z PVC outer jacket service life calculator based on 2 billion test cycles per year"
z Shielded UL/CSA AWM See data sheet for details  www.igus-asean.com/CF210UL
z Oil-resistant
NFPA Following NFPA 79-2018, chapter 12.9

Dynamic information EAC Certificate No. RU C-DE.ME77.B.00863/20
®
Bend radius e-chain linear minimum 10 x d
flexible minimum 8 x d REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
fixed minimum 5 x d
Temperature e-chain linear +5°C up to +70°C Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
®
flexible -5°C up to +70°C (following DIN EN 60811-504)
fixed -15°C up to +70°C (following DIN EN 50305) Cleanroom According to ISO Class 2. The outer jacket material of this series complies with
v max. unsupported 10m/s CF5.10.07 - tested by IPA according to standard DIN EN ISO 14644-1
gliding 2m/s CE Following 2014/35/EU
a max. 50m/s²
UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
Travel distance Unsupported travels and up to 10m for gliding applications, Class 2

Cable structure Guaranteed service life (details see page 28-29)
Conductor Stranded conductor in bending-resistant version consisting of bare copper Double strokes* 5 million 7.5 million 10 million

wires (following DIN EN 60228). Temperature, R min. R min. R min.
Core insulation Mechanically high-quality, especially low-capacitance XLPE mixture. from/to [°C] [factor x d] [factor x d] [factor x d]
+5/+15 12.5 13.5 14.5
Core structure Cores wound with high tensile strength centre elements. +15/+60 10 11 12
+60/+70 12.5 13.5 14.5
Core identification Black cores with white numbers, one green-yellow core. * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
1. Core: U / L1 / C / L+
2. Core: V / L2 Typical application areas
3. Core: W / L3 / D / L- z For medium duty applications, Class 4
Intermediate layer Foil taping over the outer layer. z Unsupported travels and up to 10m for gliding applications, Class 2
z Light oil influence, Class 2
Overall shield Bending-resistant braiding made of tinned copper wires. z No torsion, Class 1
Coverage linear approx. 55%, optical approx. 80% z Preferably indoor applications, but also outdoor ones at temperatures > 5 °C
Outer jacket Low-adhesion, oil-resistant PVC mixture, adapted to suit the requirements in z Wood/stone processing, packaging industry, feeding, handling, adjusting devices
®
e-chains (following DIN EN 50363-4-1).
Colour: Pastel orange (similar to RAL 2003)
Electrical information Part No. Number of cores and conductor Outer diameter Copper Weight
Nominal voltage 600/1,000V (following DIN VDE 0298-3) nominal cross section (d) max. index
1,000V (following UL) [mm²] [mm] [kg/km] [kg/km]
Testing voltage 4,000V (following DIN EN 50395) CF210.UL.05.04 (4G0.5)C 7.0 34 63
CF210.UL.15.04 (4G1.5)C 10.0 86 140
Properties and approvals Medium CF210.UL.25.04 (4G2.5)C 11.5 146 209
13.0
288
(4G4.0)C
195
CF210.UL.40.04
Example image Oil resistance Oil-resistant (following DIN EN 50363-4-1), Class 2 Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
UV resistance
G = with green-yellow earth core x = without earth core
ASEAN2023 ASEAN2023
322 36-month guarantee ... more than 1,350 cable types from stock ... no cutting charges UL-verified chainflex guarantee ... www.igus-asean.com/ul-verified 323
®
