CFROBOT PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CFROBOT
TPE Travel distance unsupported 1 2 3 4 5 6 ≥ 400m TPE
±180°/m ® Oil resistance none 1 2 3 4 highest ±180°/m
Spindle cable/Single core | TPE | chainflex CFROBOT Class 6.1.4.3 Torsion none 1 2 3 4 ±360°

10 million 10 x d ±180°/m UL/CSA AWM See data sheet for details  www.igus-asean.com/CFROBOT
Cycles guaranteed Bend radius, e-chain ® Torsion angle
NFPA Following NFPA 79-2018, chapter 12.9

z For torsion applications z PVC-free EAC Certificate No. RU C-DE.ME77.B.00863/20
z TPE outer jacket z UV-resistant
z Shielded z Flame-retardant REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
z Oil and bio-oil-resistant z Hydrolysis and microbe-resistant
Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)

Dynamic information Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
Bend radius flexible twisted minimum 10 x d CF34.UL.25.04.D - tested by IPA according to standard DIN EN ISO 14644-1
fixed minimum 5 x d CE Following 2014/35/EU
Temperature flexible twisted -35°C up to +90°C
fixed -50°C up to +100°C (following DIN EN 50305) UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
v max. twisted 180°/s

a max. twisted 60°/s² Guaranteed service life (details see page 28-29)
Cycles* 5 million 7.5 million 10 million
Travel distance Robots and 3D movements, Class 1 Temperature, Torsion max. Torsion max. Torsion max.
from/to [°C] [°/m] [°/m] [°/m]
Torsion Torsion ±180°, with 1m cable length, Class 3 -35/-25 ±150 ±90 ±30
-25/+70 ±180 ±120 ±60
Cable structure +70/+80 ±150 ±90 ±30
Conductor Extremely bend-resistant cable. * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife

Core insulation Mechanically high-quality TPE mixture. Typical application areas
z For heaviest duty applications with torsion movements, Class 6
Overall shield Extremely torsion-resistant tinned wound copper shield. z Especially for robots and 3D movements, Class 1
Coverage approx. 90% optical z Almost unlimited resistance to oil, also with bio-oils, Class 4
Outer jacket Low-adhesion, extremely abrasion-resistant and highly flexible TPE mixture, z Torsion ±180°, with 1m cable length, Class 3
®
adapted to suit the requirements in e-chains . z Indoor and outdoor applications, UV-resistant
Colour: jet black (similar to RAL 9005) z Robots, handling, spindle drives
Electrical information
Nominal voltage 600/1,000V (following DIN VDE 0298-3)
1,000V (following UL) Part No. Number of cores and conductor Outer diameter Copper Weight
Testing voltage 4,000V (following DIN EN 50395) nominal cross section (d) max. index
[mm²] [mm] [kg/km] [kg/km]

Properties and approvals CFROBOT.035 (1x10)C 10.5 125 194
UV resistance High CFROBOT.036 (1x16)C 12.0 189 269
CFROBOT.037 (1x25)C 14.5 298 392
Oil resistance Oil-resistant (following DIN EN 60811-404), bio-oil-resistant (following VDMA CFROBOT.038 (1x35)C 15.5 403 528
24568 with Plantocut 8 S-MB tested by DEA), Class 4 Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core
Flame-retardant According to IEC 60332-1-2, Cable Flame, VW-1, FT1, FT2 / Horizontal Flame

Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
1992) Cables available in the chainflex CASE
®
Certificate No. B129699: "igus 36-month chainflex cable guarantee and
Example image service life calculator based on 2 billion test cycles per year" More on this on page 24/25 and online: www.igus-asean.com/cf-case
UL verified
Simple savings on delivery, storage space and re-ordering with
®
®
the chainflex CASE - ship'n store by igus .
EPLAN download, configurators  www.igus-asean.com/CFROBOT
404 36-month guarantee ... more than 1,350 cable types from stock ... no cutting charges ASEAN2023 ASEAN2023 UL-verified chainflex guarantee ... www.igus-asean.com/ul-verified 405
®
