chainfix chainfix strain relief | Clamps | Advantages chainfix strain relief | Clamps chainfix

Product range and materials For the following
®
● Steel clamp: clamp and screw black painted steel igus series
● Stainless steel clamp: clamp and screw: blank (material AISI 304) E2.1
● Stacker elements: bottom saddle and stacker saddle (igumid G material) ● E2.38
● Steel C-profile available (material galvanised steel) ● E2.48
● Stainless steel C-profile available (material AISI 304) E2/000
● 2600/2700/2650/2680
Installation height ● 3400/3500/3450/3480
If the e-chain glides on itself for long travels, the screw heads of the strain relief at the fixed end E4.1L
®
of the e-chain must have a distance of at least 10mm from the top of the e-chain . As a result, ● E4.38L/R4.38L
®
®
many strain relief elements described here may not be suitable for use at the fixed end on long ● E4.48L/R4.48L
gliding e-chains . For unsupported e-chains strain relief elements can always be safely used. ● E4.64L
®
®
E4Q
● E4Q.34/H4Q.34
● E4Q.44/H4Q.44
● E4Q.58/H4Q.58
● E4Q.82/H4Q.82
E4.1
Please note ● E4.32/H4.32/R4.32
®
● Ideally, the cables should be secured at both ends of the e-chain with strain relief. As a ● E4.42/H4.42/R4.42
Can be integrated For up to three Reduced High strength for minimum they need to be attached at the moving end of the e-chain ! ● E4.56/H4.56/R4.56
®
into igus KMA cables stacked installation height, dynamic applications ● When using chainfix clamps on C-profiles in the mounting bracket for series ● E4.80/H4.80/R4.80
®
mounting bracket above one another space-saving E4.38L/R4.38L, E4Q.34/H4Q.34, E4.32/H4.32/R4.32 (also for the classic series ● E4.112/R4.112
280/290/R770, 2828/2928/R7728) a shortened bottom saddle must be used. ● E4.162
chainfix clamps - fitted For shortened bottom saddles supplement Part No. with index "K". Example: E4/light

CFX12.1K
14040/14140/18840
●
quickly and securely ● 14240/14340
14550/14650/19050
●
● 15050/15150/19850
● New: now also cost-effective strain relief for large hose and cable diameters - new sizes for cable ● 15250/15350
diameters 42mm - 46mm and 46mm - 50mm are available E6.1
● chainfix clamps with up to 15mm reduced installation height compared to conventional clamps due to ● E61.40
optimised housing height ● E61.52
● Tested in the igus laboratory - up to 3.5 times higher force absorption compared to conventional clamps ● E61.62
®
● Easy to read the part number and mark indicating the correct installation direction ● E61.80
● Space and time-saving assembly E6
● Delivery options for complete systems with cables and preassembled strain relief CFX - chainfix housing with reduced height Save both time and space during installation ● E6.40
● Improved base for easier fit into the C-profile with igus chainfix clamps ● E6.52/R6.52
®
● Simple assembly with hex head set screw ● E6.62
● High strength for dynamic applications with improved stacker elements ● E6.80L
● Built-in ribs on the stacker elements give secure grip on the cables ● E6.80
● Optional: CFXL clamps for increased holding force for heavy-duty applications (Note: CFXL clamps
are always assembled in front of the e-chain . They cannot be integrated into KMA mounting brackets
®
with C-profile option!)

Available from stock. Ready to ship in 24 - 48hrs.*
*The delivery times indicated correspond to the average time until the ordered goods are dispatched.
