2Allowable Load
Basic Rated Load Static Allowable Moment Mass
Nominal model C (Dynamic) Co (Static) MA·MB MC Blocks Guide Rails
kN kN N·m N·m kg kg/m
7 1.37 1.96 4.8 7.64 0.015 0.22 2

9 2.55 4.02 18.62 19.6 0.026 0.38

12 3.72 5.88 36.26 38.22 0.054 0.65 Bushings / Oil Free Bushings Linear Guides / Linear
15 6.37 9.11 57.82 73.5 0.092 1.06

2Details of the Dimensions about L Dimension Confi gurable Type
L Dimension specifi ed type cuts both ends of the slide rail equally. Refer to the table below for the number of mounting holes
(M) of the slide rail at this time. Linear Guides Miniature
In addition, E dimension is calculated with the formula below.
L-(M-1)×P
E= 2
P.113
Number of
H 8 10 13 16 Mounting Holes
M Guides Linear
- - - 70~87 2
40~50 45~47 60~82 88~127 3
51~65 48~67 83~107 128~167 4 P.123
66~80 68~87 108~132 168~207 5
81~95 88~107 133~157 208~247 6
96~110 108~127 158~182 248~287 7 Bushings Linear
111~125 128~147 183~207 288~327 8
126~130 148~167 208~232 328~367 9
- 168~187 233~257 368~407 10 P.139
L
- 188~207 258~282 408~447 11
- 208~227 283~307 448~487 12 Bushings
- 680~739 308~332 488~527 13 Oil Free
- 228~247 333~357 528~567 14
- 248~267 358~382 568~607 15 P.161
- 268~275 383~407 608~647 16
- - 408~432 648~670 17
- - 433~457 - 18 Supports Shaft
- - 458~470 - 19
P 15 20 25 40
P.170
Example Collars Shaft

P.173

Automatic cutting unit
Autom
In orde
In order to stably cut and send out, prevent
off set,
off set, swing and ensure handling accuracy,
two rows of parallel miniature rail tracks are
two ro
used. d
