                                                                                 Economy Series
          Product Specifications                                                    Lead Screws


          2 Lead screw Specification                                                                 Lead Screws / Actuators  Ball Screws /


                                           Both Ends Stepped                   One End Stepped One End
              Type          Straight                           Both Ends Stepped
                                            For Support Units                      Double Stepped     Ball Screws


                                                                                                     P.31
             Shape



                                                                                                      Precision
                                                                                                     Ball Screws
          * For more shaft end shapes, please visit MISUMI official website.                         P.49
                                                                                            Unit: mm
                                                         Screw Shaft Runout (Max.)
                 Screw  Screw  Screw
          Shaft  Shaft  Shaft  Shaft                       Shaft Overall Length                      for Ball Screw  Support Units
           Dia.  Pitch Effective Minor Dia.  Lead
                 Dia.  (MIN)  Angle
                                 ~125  126~200  201~315  316~400  401~500  501~630  631~800  801~1000 1001~1250 1251~1600 1601~2000
                                                                                                     P.61
            8  1.5  7.25  (5.9)  3°46'  0.1  0.14  0.21  0.27  0.35  -  -   -
                                                                                  -     -     -
           10  2  9   (7.2 )  4°03'
                                 0.09  0.12  0.16  0.21  0.27  0.35  0.46  0.58                      Brackets  Motor
           12  2  11  (9.2)  3°19'
                                                                                                     P.69
           14  3  12.5  (10.1)  4°22'                                             -     -     -
                                 0.09
           16  3  14.5  (12.1)  3°46'  0.11  0.13  0.16  0.2   0.25  0.32  0.42
                                                                                 0.55  0.73   1       Lead Screws
           20  4  18  (15.1)  4°03'  -
           22  5  19.5  (16.1)  4°40'                                                                P.71
                                  -    0.09  0.11  0.13  0.16  0.19  0.23   0.3  0.38   0.5  0.69
           25  5  22.5  (19)  4°03'                                                                  Nuts  Lead Screw


          2 Lead screw Nut Specification                                                             P.83


                                                        Type
                                    Standard Type                   Compact Type        Block Type   Support Units   Lead Screw
                       Round Flanged  Cut Flange 2-hole  Cut Flange 4-hole  Round Flanged  Cut Flange 2-hole  Wide Block
                                                                                                     P.86
            Shaft  Pitch
            Dia.                                                                                     Stop Plates  Lead Screw

                                                                                                     P.90


                                                     Allowable Dynamic Thrust (N)                     Actuators
             8    1.5            1250                —           —            —           —
            10     2                   2168                     1717          —           2168       P.99
            12     2                   3332                     2669          —           3332
            14     3                   4165                            3332               4165
            16     3                   5670                            4539               5670
            20     4                   8339                            6673               8339
            22     5                   10506                           8407              10506
            25     5                   12087                           9673              12087
